147378-7

点击放大查看

147378-7

制造商
TE Connectivity Ltd.
描述Conn Socket Strip RCP 80 POS 1.27mm Solder ST SMD T/R .050 X .100 AMPMODU System 50 CONN RCPT 80POS DL ROW SMD GOLD Board to Board & Mezzanine Connectors 80 SYS50 SMT RCP DR SHD W/O HD 80 SYS50 SMT RCP DR SHD W/O HD 80 SYS50 SMT RCP DR SHD W/O HD Search Keywords:wire to wire, wire to board, IDC, latching, high density, co-planar, horizontal, pcb connectors, AMPMODU
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMPMODU标准包装规格300
产品类别Board to Board & Mezzanine Connectors标准包装数量Tape & Reel

合规参数

RoHSContains lead / RoHS non-compliant无铅定义Reflow solder capable to 245°C, Reflow solder capable to 260°C
标准编号CSA LR7189, UL E28476RoHS/ELV合规状态ELV compliant, 5 of 6 Compliant
材料阻燃等级UL 94V-0

电气参数

额定电压30 V供电电压30
输入电阻5000额定交流电压30
连接器阻抗不带击穿电压500
绝缘电阻5,000

机械参数

颜色Black间距1.27 mm
高度9.398 mm [ .37 in ]包装方式Tape & Reel (TR)
壳体颜色黑色排间距0.100" (2.54mm)
端接方式Solder外壳颜色Black
安装类型Vertical连接器类型Receptacle
接触镀层Gold Over Nickel安装样式Surface Mount
排数2插入件材料磷青铜
触头材料Phosphor Bronze壳体材料Thermoplastic Glass Reinforced
包装数量Tape & Reel面板安装类型表面贴装
端接样式SMD板面高度0.370" (9.40mm)
触点数80位数80
衬套/护套类型不带兼容外壳尺寸（如TM-700等）与接头配合
接触镀层厚度30µin (0.76µm)

产品信息

类型Socket Strip连接器性别RCP
系列AMPMODU SYSTEM 50制造商全称AMP
产品子类型Receptacle Assembly装配配置无
加载位置数All

环境参数

温度范围-65 – +105工作温度-65 – 125

文档与媒体

在线文档
147378-7?RQPN=147378-7
