1769078

点击放大查看

1769078

制造商
Phoenix Contact GmbH & Co. KG
描述Pluggable Terminal Blocks MSTBP 2.5/ 8-ST-5.08 Conn Terminal Block F 8 POS 5.08mm Screw RA Cable Mount 12A TERM BLOCK PLUG 8POS STR 5.08MM Printed-circuit board connector MSTBP 2,5/ 8-ST-5,08 MSTBP25/8-ST-508 Phoenix Contact COMBICON MSTBP 系列 5.08mm 节距 8 路 母 绿色 插头, 螺钉端接
分类
连接器解决方案接线端子螺丝接线端子
对参数有疑问？问 AI 助手

商业参数

产品Plugs交货时间31 Days
商标名COMBICON Control子类别Connector Terminal Blocks
产品类别Pluggable Terminal Blocks标准包装数量50
工厂包装数量50

合规参数

RoHSRoHS Compliant

电气参数

电流15A电压300V
额定电压250 V最大额定电流12 A

机械参数

颜色Green深度21.3
间距5.08 mm高度15
长度40.64重量4.550341 oz
材料（通用）聚酰胺，镀锡端部样式Screw
包装方式Bulk导线线规12-30 AWG
方向Right Angle端接方式Screw
安装类型Free Hanging (In-Line)连接器类型母座
接触镀层Tin插头进线方向180°
端接排数螺钉端接样式Screw
触点数8位数8
接线端子类型Plug, Female Sockets绝缘材料 - 材质Polyamide
线规或范围 - AWG24-12

产品信息

类型Terminal Block连接器性别F
系列MSTBP产品特性Retention Latches (Non-Wire Side)
行业别名MSTBP 2, 5/ 8-ST-5, 08层数1
每层位数8其他规格1
装配配置Cable Mount

文档与媒体

PDF 文档
1769078
