点击放大查看

2-42937-6599

制造商	TE Connectivity Ltd.
描述	CONN DIN RECEPT 96POS VERT PCB
分类	连接器解决方案背板连接器DIN 41612

对参数有疑问？问 AI 助手

商业参数

标准包装数量

合规参数

材料阻燃等级

UL94 V-0

机械参数

间距	0.100" (2.54mm)	包装方式	Bulk
端接方式	Solder	安装类型	Through Hole
连接器类型	Receptacle, Female Sockets	接触镀层	Gold
排数	3	位数	96
绝缘材料 - 材质	Polyester, Glass Filled	接触镀层厚度	30µin (0.76µm)

产品信息

样式	C	产品特性	Board Lock
加载位置数	All

环境参数

级别、等级

工作温度

-55°C ~ 125°C
