点击放大查看
796642-2
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Shrouded Header HDR 2 POS 5mm Solder ST Thru-Hole Terminal Block Connectors TERM BLOCK HDR 2POS VERT 5MM Pluggable Terminal Blocks 2POS 5.0MM CE VRT HD Conn Shrouded Header HDR 2 POS 5mm Solder ST Thru-Hole Search Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end TERMINAL BLOCK, HEADER, 5MM, 2WAY 2POS 5.0MM CE VRT HDR,TRM BLK |
| 分类 |
商业参数
| 产品 | Pluggable Terminal Blocks | 产品类别 | Pluggable Terminal Blocks |
| 标准包装数量 | Bulk | 工厂包装数量 | 300 |
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85369010 |
| 材料阻燃等级 | UL 94 V-0 | ||
电气参数
| 电流 | 15A | 电压 | 300V |
| 额定电压 | 300 VAC | 最大额定电流 | 15 A |
| 最小供电电压 | 300VAC | ||
机械参数
| 颜色 | Green | 深度 | 8.35 mm |
| 间距 | 5 mm | 高度 | 12 mm |
| 重量 | 0.02 | 包装方式 | Bulk |
| 引脚样式 | Vertical | 导线线规 | 30 |
| 端接方式 | Solder | 外壳颜色 | Green |
| 安装类型 | Through Hole | 连接器类型 | :PCB Terminal Block |
| 接触镀层 | Tin | 安装样式 | Through Hole |
| 排数 | 1 | 触头材料 | Phosphor Bronze |
| 壳体材料 | Polyamide (PA) | 总长度 | 12 mm |
| 端接样式 | Through Hole | 排针方向 | Vertical |
| 触点数 | 2 | 位数 | 2 |
| 接线端子类型 | Header, Male Pins, Shrouded (4 Side) | 线规或范围 - AWG | 30-12 |
| 线规或范围 - mm² | 12 | 第一连接器安装类型 | :PCB |
产品信息
| 类型 | Shrouded Header | 连接器性别 | HDR |
| 系列 | :BUCHANAN | 层数 | 1 |
| 每层位数 | 2 | ||
环境参数
| 工作温度 | -40C to 105C | ||
