640453-7

点击放大查看

640453-7

制造商
TE Connectivity Ltd.
描述Conn Unshrouded Header HDR 7 POS 2.54mm Solder RA Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER RTANG 7POS .100 TIN Headers & Wire Housings FLAT HEADER 7P Right Angle Post tin Header;MTA-100;7;250VAC;Polyester;Tin;CopperAlloy;0.100in.;Tin;AMP 07P MTA100 HDR ASSY SQ R/A
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

其他名称A19342产品类别Headers & Wire Housings
标准包装数量Bulk工厂包装数量1

合规参数

RoHSLead free / RoHS Compliant标准RoHSCompliant,ELVCompliant,UL94V-0
UL等级获得认可无铅定义Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c
UL档案号E28476认证机构CSA,UL
CSA档案号LR7189标准编号CSA, UL
CSA认证CertifiedRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL 94V-0

电气参数

额定电压250 V供电电压250
额定交流电压250连接器阻抗焊接
最大额定电流5 A

机械参数

颜色Natural间距2.54 mm
长度17.78 mm [ .7 in ]包装方式Bulk
端口尺寸0.025in.遮蔽类型No
壳体颜色自然导线线规28-22
端接方式Solder触头类型Male Pin
引脚长度（针脚）0.14"第二连接器Without
触点形状Square外壳颜色White
安装类型Right Angle行程角度Right
连接器类型Header, Unshrouded接触镀层Tin Over Nickel
触点时序Without安装样式PCMount
排数1壳体镀层Tin
外壳材料（壳体）普通连接器用途Header
插入件材料铜合金触头材料Copper Alloy
壳体材料Polyester总长度0.7"
安装特性Without包装数量1
面板安装类型Without主要材料InterconnectSystem
尺寸/外形0.64 [.025]插针孔直径0.1"
端接样式Through Hole第一触头极性Pin (Male)
配接方向Without触点数7
端接表面处理不带接触件端接Tin
绝缘直径0.06"(SingleWire),0.05"(MassTerminationWires)位数7
后壳中断功能Without兼容外壳尺寸（如TM-700等）MTA .100 连接器组件
触头长度-柱3.56 mm [ .14 in ]中心触点镀层工艺0.100in.
柱体长度（配合）0.14in.安装孔直径0.04"
接触件表面处理 - 配合锡典型触点布局2.54 [0.100]
接触长度 - 配合0.295" (7.49mm)触点材料 - 柱Copper Alloy
表面贴装焊盘尺寸Without端子柱长度3.56 [0.140]
接触镀层厚度3.81 µm [ 150 µin ]恢复后小径No
静电放电屏蔽不带护套（绝缘）厚度1.27 µm, 50 µin

产品信息

类型Unshrouded Header连接器性别HDR
系列MTA-100产品特性IDC,Pinstrip
可密封否制造商全称AMP
产品子类型MTA-100 Connectors连接类型Printed Circuit Board
应用细节Wire-to-Board加载位置数All
跳过的位置数None

环境参数

工作温度-55to+105°C封装热阻1.6 mm [ .063 in ]
