点击放大查看
5747098-1
| 制造商 | TE Connectivity Ltd. |
| 描述 | Connector Accessories Backshell/Cable Clamp Thermoplastic Individual D-Sub Backshells DSUB ACC: D CABLE CLAMP SHLD Cable Clamps BACKSHELL 50POS SHIELDED EMI Backshell/Cable Clamp 180� 5 Shell Size Nickel Over Copper Thermoplastic Individual Backshell/Cable Clamp 180° 5 Shell Size Nickel Over Copper Thermoplastic Individual Backshell/Cable Clamp 180° 5 Shell Size Nickel Over Copper Thermoplastic Individual Product Highlights:Backshell/Cable ClampCable Clamp Type = Two-Piece RFI/EMI Shield180° Cable Exit AngleCable Insulation Diameter = 19.05 mmShell Size = 5Search Keywords:AMPLIMITE, Subminiature D, input/output, box to box, d-sub, d sub, dsub CABLE CLAMP KIT, SIZE 5, THERMOPLASTIC CABLE CLAMP KIT,SZ 5 |
| 分类 |
商业参数
| 交货时间 | 70 Days | 子类别 | Backshells |
| 产品类别 | D-Sub Backshells | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85366910 |
机械参数
| 颜色 | Silver | 深度 | 48.76 mm |
| 高度 | 22.86 mm | 重量 | 0.00001 |
| 镀层 | Nickel over Copper | 材料（通用） | Thermoplastic |
| 包装方式 | Bulk | 屏蔽 | Shielded |
| 出线方向 | 180° | 电缆类型 | Round |
| 外壳尺寸 | 5 | 外壳镀层 | Nickel over Copper |
| 电缆直径 | 19.05 mm | 电缆端类型 | Straight |
| 本体材料 | :Thermoplastic | 位数 | 50 |
| 外壳尺寸-插件 | :DD | 电缆对数 | 1 |
| 外部壳体材料 | :Plastic | ||
产品信息
| 类型 | Backshell/Cable Clamp | 系列 | :AMPLIMITE |
| 产品特性 | Assembly Kit, Mating Screws 4-40 | 硬件配件 | Assembly Hardware, Strain Relief |
| 附件类型 | Two Piece Backshell | 射频系列/标准 | 5747098 |
| 适用产品/相关产品 | 747098-1 | ||
