5223955-2

点击放大查看

5223955-2

制造商
TE Connectivity Ltd.
描述Conn Power RCP 3 POS 3mm Press Fit ST Thru-Hole 3 Terminal 1 Port Universal Power Module (For use with Z-PACK 2mm HM, Z-PACK HS3, Z-PACK HM-Zd and MULTI GIG RT2J) CONN RCPT 3POS STR UNIVER Z-PACK Female Compact Power Connector Socket Through Hole,Press-In Termination Hard Metric Connectors REC 1X003P VRT B-PLANE UPM high speed backplane connectors Conn Power RCP 3 POS 3mm Press Fit ST Thru-Hole 3 Terminal 1 Port Search Keywords:high speed, board to board, open pin field, power, IEC 950, inverse-sex, mezzanine, pcb connectors, wire to board, VRM, voltage regulator module, Itanium II Power POD connector, HARD METRIC CONNECTOR, RECEPTACLE, 3POS RECEPTACLE,UNIVERSALPOWERMODULE,3POSITION,VERTICAL 3 Position Vertical Receptacle Through Hole Press Fit Universal Power Module TE Connectivity 背板连接器 插座 母, 通孔安装, 按式端接 UNV PWR MDL ASY RECEPT
分类
工具与焊接解决方案压接钳、压接机、压力机压接钳
对参数有疑问？问 AI 助手

商业参数

零件号别名5-223955-2产品类别Hard Metric Connectors
标准包装数量Rail / Tube工厂包装数量60

合规参数

RoHSLead free / RoHS Compliant海关税号85369010
无铅定义Not relevant for lead free processRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL94 V-0

电气参数

额定电压250V连接器类型 - 电压输入Socket

机械参数

颜色Gray深度11.35 mm
间距3 mm高度12.15 mm
重量0.002直径Not Required mm
包装方式Tube端接方式Press Fit
触头类型Compliant Post外壳颜色Gray
安装类型Through Hole连接器类型Receptacle, Female Blade Sockets
接触镀层Tin安装样式Through Hole
排数1连接器样式Blade Power
连接器用途Backplane触头材料Phosphor Bronze
壳体材料Polyester总长度9.5 mm
端接样式Press Fit触点数3
接触件端接:Press Fit Vertical位数3
典型触点布局3 Power接触镀层厚度3µin (0.08µm)

产品信息

备注Contact area lubricated with Bellcore approved lubricant.类型Power
连接器性别RCP系列Z-Pack
已删除Compliant编码、键控No
产品子类型Receptacle端口数1 Port
列数3加载位置数All

环境参数

工作温度-55°C ~ 125°C

文档与媒体

PDF 文档
1650929.pdf
在线文档
5223955-2?RQPN=5223955-2
