1658622-6

点击放大查看

1658622-6

制造商
TE Connectivity Ltd.
描述Conn IDC Connector F 26 POS 2.54mm IDT RA Cable Mount Ribbon Cable Connectors (AMP-LATCH) CONN IDC SKT 26POS W/POL GOLD AMP-Latch receptacle,0.08-0.15mm²,26way Headers & Wire Housings .1CL IDC REC 2X13P C&M 30AU Conn IDC Connector F 26 POS 2.54mm IDT RA Cable Mount Product Highlights:Connector Type = NOVONumber of Positions = 26ReceptacleMating Polarization Method = Center & MilitaryWith Mating PolarizationSearch Keywords:input/output, paddleboard, paddle board WIRE-BOARD CONNECTOR RECEPTACLE 26POS, 2.54MM Connector,Receptacle;Novo;26;Gold(30);Tin-Lead;0.100in.x0.100in. TE Connectivity AMP-LATCH Novo 系列 2行 26路 2.54mm节距 直角 电缆安装 母 IDC 连接器 26 NOVO MIL/CTR 30DP,LEAD FREE
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMP-LATCH产品类别Headers & Wire Housings
标准包装数量Rail / Tube工厂包装数量60

合规参数

RoHSLead free / RoHS Compliant海关税号85366910
无铅定义Not relevant for lead free processRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL 94V-0

电气参数

量程（°/s）:TE - AMP-LATCH Novo Series最大额定电流1A
最小供电电压250VAC

机械参数

颜色Black深度8.36mm
间距2.54 mm宽度7.49mm
高度7.49 mm长度37.59mm
重量0.005包装方式Bulk
导线类型Ribbon Cable出线方向Without
导线线规26-28 AWG排间距0.100" (2.54mm)
端接方式IDT触头类型Female Socket
极化Center & Military第二连接器Without
外壳颜色Black安装类型No
电缆端类型Without连接器类型NOVO
接触镀层Gold Over Palladium Nickel Over Nickel|Gold Over Nickel安装样式Cable
排数2触头材料Phosphor Bronze
壳体材料Thermoplastic总长度37.59 mm
安装特性Without尺寸/外形37.59 x 7.49 x 8.36mm
电缆端接方式IDC端接样式IDC
第一触头极性Socket (Female)配接方向With
触点数26接触件端接:IDC / IDT
位数26中心触点材料2.54 x 2.54 [.100 x .100]
接触镀层厚度30µin (0.76µm)

产品信息

类型IDC Connector连接器性别F
系列AMP-LATCH NOVO产品特性Feed Through, Polarizing Key
产品子类型Receptacles / Sockets - Housings连接类型Ribbon Cable
带调制解调器控制Yes应用细节Wire-to-Board
