点击放大查看

XG5M-1032-N

制造商	Omron Corporation
描述	ヘッダ & ワイヤハウジング IDC 2Row Socket 10P Size1 1PolarizeGuide Conn Housing SKT 10 POS 2.54mm Crimp ST CONN DBL ROW SOCKETS 10POS AWG24 Headers & Wire Housings IDC 2Row Socket 10P Size1 1PolarizeGuide 欧姆龙(OMRON) 其它传感器附件
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

交货时间	89 Days	子类别	Connector Discrete Wire Housing
零件号别名	1756293 385312	产品类别	Headers & Wire Housings
标准包装数量	180	工厂包装数量	180

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Compliant

电气参数

额定电压	300 V	最大额定电流	3 A
最小输入电压	300VAC

机械参数

颜色	Black	深度	14.4
间距	0.100" (2.54mm)	高度	7.1
包装方式	Bulk	导线类型	Discrete
导线线规	24 AWG	排间距	0.100" (2.54mm)
触头类型	Female Socket	外壳颜色	Black
安装类型	Straight	连接器类型	Receptacle
接触镀层	Gold	安装样式	Wire
排数	2	壳体材料	Polybutylene Terephthalate
总长度	17.3	电缆端接方式	IDC
端接样式	IDC	触点数	10
位数	10	接触镀层厚度	5.9µin (0.15µm)

产品信息

类型	Housing	连接器性别	SKT
系列	XG5	产品特性	Closed End, Polarizing Key
产品子类型	Receptacles / Sockets - Housings	行业别名	XG5M-1032-N

文档与媒体

PDF 文档

How to Read Date Codes

PDF 文档

XG5_1110.pdf
