SA3180
| 制造商 | Bulgin |
| 描述 | Standard Circular Contacts CRIMP PIN 12P 24AWG 1 = 1 PKT of 10/pcs CONT PIN 1A CRMP 24-28AWG 1=10PC Bulgin 400 Series Gold Plated Crimp Pin Connector, 28 to 24AWG Contact PIN Crimp ST Cable Mount CRIMP PIN, PK10 Contacts,Standard,Buccaneer,25-Way,Crimp Contact; male; 24÷28AWG; Buccaneer 400; gold plated; crimped; 1A Crimp contact, male, for 10 and 12-pole, SA3180, Bulgin Bulgin 400 系列 公 压接端接 圆形 连接器 触芯, 使用于Buccaneer 400 系列连接器, 28 → 24 AWG 线规格 |
| 分类 |
商业参数
| 其他名称 | 708-1090 | 产品类别 | Standard Circular Contacts |
| 标准包装数量 | 1 | 工厂包装数量 | 50 |
合规参数
| RoHS | Compliant | SVHC | :No SVHC (19-Dec-2012) |
| 海关税号 | 85369010 | ||
电气参数
| 额定电压 | 50 V | 接触电阻 | 5mΩ |
| 最大额定电流 | 1 A | 连接器类型 - 电压输入 | 10pin connectors, 12pin connectors |
机械参数
| 重量 | 0.002 | 包装方式 | Bulk |
| 导线线规 | 24-28 AWG | 端接方式 | Crimp |
| 安装类型 | crimped | 插针或插孔 | Pin |
| 连接器类型 | male | 接触镀层 | Gold |
| 触头材料 | Copper Alloy | 包装数量 | 100 |
| 连接器 - 电缆 | contact | 第一触头极性 | Pin (Male) |
| 接触件端接 | Crimp | 线规或范围 - AWG | :28AWG |
| 线规或范围 - mm² | :0.25mm² | 触点材料 - 镀层 | gold plated |
| 外径-未扩张 | :0.51mm | ||
产品信息
| SPG | 100 | 连接器性别 | Male |
| 系列 | 400 | 适配器系列 | Buccaneer 400 |
| 单元数量 | 10 | 适用产品/相关产品 | :Buccaneer 400 Series Circular Connectors |
环境参数
| 防护等级 | IP 68 | 工作温度 | 80°C |
文档与媒体
相关型号
14025
Bulgin
Crimpers CRIMP TOOL FOR 400S TOOL CRIMP USE W/POSITIONERS Crimp tool; 8 Indent; for use with positioners Crimp Tools For 3, 9,12 And 25 Pole Crimp Contacts CRIMP TOOL, 400 SERIES Crimptool,8Indent,forusewithpositioners Crimping pliers without limit stop, 14025, Bulgin
13027
Bulgin
Hand Tools INSERTION/EXTRA TOOL TOOL INSERT/EXTRACT Insertion tool for 1A contacts Insertion/Extraction Tool 3, 9,12 And 25 Pole Crimp Contacts INSERTION TOOL, 24-28AWG Tool,Assembly;25 Bulgin 400 系列 插入工具
13170
