5120-B7A2PL

点击放大查看

5120-B7A2PL

制造商
3M Company
描述=20/2R/BM SKT/.100/RA/FLG/.112/15AVG .100" × .100" Centerbump Polarization with Right Angle Solder Tails CONN SOCKET 20POS R/A DL .100" 3M 2.54mm 20 Way 2 Row Right Angle PCB Socket Through Hole Board to Board Headers & Wire Housings 20P R/A PLRZD SKT SOCKET, PCB, RIGHT ANGLE, 20WAY 20WR/ABOARDMOUNTSOCKET 3M 5100 系列 2行 20路 直角 2.54mm节距 通孔 印刷电路板插座, 板对板 20P RIGHT ANGLE BM SOCKET
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

零件号别名54745251417 JE150344180产品类别Headers & Wire Housings
标准包装数量100工厂包装数量100

合规参数

RoHSCompliant海关税号85366930

电气参数

极数:20工作电压:350V
最大额定电流1A绝缘电阻:1000Mohm

机械参数

颜色Gray间距0.100" (2.54mm)
重量0.015包装方式Bulk
排间距0.100" (2.54mm)端接方式Solder
触头类型Female Socket引脚间距:2.54mm
安装类型Through Hole, Right Angle连接器类型Receptacle
接触镀层Gold排数2
触头材料Copper Alloy第一触头极性Socket (Female)
连接器颜色:Grey触点数20
接触件端接:Through Hole Right Angle位数20
接触镀层厚度30µin (0.76µm)

产品信息

类型Board to Board连接器性别:Receptacle
系列5100产品特性Polarizing Key
极性:Bump产品子类型Socket Headers
加载位置数All

环境参数

插拔次数:200工作温度:105°C

文档与媒体

压缩文件
5120-B7A2xx.igs
压缩文件
5120-B7A2xx.stp
PDF 文档
91726.pdf
