图片仅供参考,产品以实物为准
#1 |
数量:18 |
|
最小起订量:1 美国加州 当天发货，1-3个工作日送达. |
|
|||||||||||||||
#2 |
数量:24 |
|
最小起订量:1 阿姆斯特丹 当天发货，5-8个工作日送达. |
|
|||||||||||||||
#3 |
数量:24 |
|
最小起订量:1 荷兰阿姆斯特丹 当天发货，5-8个工作日送达. |
|
| 规格书 |
 |
| Status | Active |
| 工厂包装数量 | 10 |
| 产品种类 | Loudspeaker Connectors |
| 额定电流 | 40 A |
| 额定电压 | 250 V |
| 颜色 | Black |
| 性别 | Female |
| 单位重量 | 2.504451 oz |
| 标准 | Speakon, HPC |
| 安装风格 | Chassis (Panel) |
| 位置/触点数 | 4 |
| 触点电镀 | Silver |
| RoHS | RoHS Compliant |
| 触点材料 | Spring Copper |
| 系列 | :speakON STX |
| No. of Contacts | :4 |
| Connector Colour | :- |
| 接触端子 | :Solder |
| Connector Mounting | :Chassis |
| Connector Body Material | :Metal |
| SVHC | :No SVHC (20-Jun-2013) |
| Connector Mounting Orientation | :Panel |
| 端接方式 | :Solder |
| Weight (kg) | 0.072 |
| Tariff No. | 85369010 |
| AgencyApprovals | UL,CSA |
| Angle | Straight |
| Brand/Series | STXSeries |
| CableSize | 9to16mm |
| ContactPlating | Silver |
| CurrentRating | 40A |
| Current,Rating | 40A(Continuous),50A(Audiosignal) |
| FlammabilityRating | UL94HB |
| Flammability,Housing | UL94HB |
| InsulationType | Uninsulated |
| Material,Body | ZincDie-Cast |
| Material,Contact | SpringCopper |
| Material,Housing | ZincDiecast |
| MountingType | Panel |
| NumberofContacts | 4 |
| NumberofPoles | 4 |
| PrimaryType | Speaker |
| Resistance,Insulation | >10Gigaohms |
| TemperatureRange | -30to+80°C |
| 端子 | Thru-Hole |
| 类型 | Jack |
| Voltage,Rating | 250V |
| RoHS指令 | RoHS Compliant Part |
