1757828-2
| 制造商 | TE Connectivity Ltd. |
| 描述 | D-Sub Standard Connectors RCPT ASSY POSTD 109 ZN 2 Subminiature D Pin/Socket Connectors for MIL-C-24308 and MIL-C-39029 Conn D-Subminiature SKT 15 POS 2.77mm Solder ST Thru-Hole 15 Terminal 1 Port Conn D-Subminiature SKT 15 POS 2.77mm Solder ST Thru-Hole 15 Terminal 1 Port Product Highlights:ConnectorProduct Series = 109Density = StandardTerminate To Printed Circuit Board15 PositionsSearch Keywords:AMPLIMITE, rack and panel, MIL-M24519, DIN 41652, input/output, box to box, military/aerospace, d-sub, d sub, dsub AMPLIMITE,RCPT ASY,POSTD,109,ZN,2 |
| 分类 |
商业参数
| 零件号别名 | M24308 M24308/23-2 | 产品类别 | D-Sub Standard Connectors |
合规参数
| RoHS | RoHS Compliant | 抗辐射加固 | No |
| 资质认证 | No | 无铅定义 | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| RoHS/ELV合规状态 | RoHS compliant, ELV compliant | 认证机构标志 | Yes |
电气参数
| 连接器阻抗 | No | 连接器类型 - 电压输入 | No |
机械参数
| 深度 | 12.93 mm | 间距 | 2.77 mm |
| 高度 | 12.87 mm | 外形尺寸(长x宽) | 2 |
| 直径 | 0.76 [0.030] | 包装方式 | 包装 |
| 外壳尺寸 | 2 | 端接方式 | Solder |
| 触点尺寸 | 20 | 非磁性 | No |
| 外壳表面处理 | 锌 | 安装类型 | Vertical |
| 外壳镀层 | Zinc | 端子尺寸 | 20 |
| 连接器类型 | SKT | 接触镀层 | Gold |
| 安装样式 | Through Hole | 排数 | 2 |
| 外壳材料（壳体） | Steel | 插入件材料 | Aluminum Alloy |
| 触头材料 | Brass, Beryllium Copper | 壳体材料 | Polyphenylene Sulfid |
| 总长度 | 39.52 mm | 面板安装类型 | 垂直 |
| 连接器 - 电缆 | 否 | 端接样式 | Through Hole |
| 触点数 | 15 | 位数 | 15 |
| 镀层厚度（通用） | Clear Blue Trichromate | 衬套/护套类型 | No |
| 安装孔直径 | 3.05 [.120] | 端子柱长度 | 3.95 [0.156] |
产品信息
| 备注 | 按照规定，连接器上 M24308 料号后面会冲压 Z。“Z”表示镀锌外壳。 | 类型 | D-Subminiature |
| 连接器性别 | Receptacle | 系列 | 109 |
| 密度 | Standard | 排列方式 | MS18274-1 |
| 插座类型 | With | 制造商全称 | Tyco Electronics |
| 产品子类型 | Connector | 连接类型 | Printed Circuit Board |
| 端口数 | 1 Port | 设备部件号 | M24308/23-2 |
