794190-1
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing PL 6 POS 4.14mm ST Individual Pin & Socket Connectors 06P MINI PLUG .163" Centerline, 600 V, 9.5 A max. CONN PLUG 6POS MINI UNIV-MATE 2 Housing,plug,mini Mate-n-lok,2 row,6 Way Conn Housing PL 6 POS 4.14mm ST Individual Product Highlights:HousingMini-Universal MATE-N-LOK 2Number of Circuits = 64.14 x 4.14 mm Centerline, MatrixDouble-Row Contact LayoutSearch Keywords:soft shell, high density, wire to wire, wire to board, Lighting Interconnection, pcb connectors, discrete wire, crimp, Mini-Universal MATE-N-LOK, PWRSIGALLP PLUG AND SOCKET CONNECTOR HOUSING HOUSING,PLUG,MINI-UNIVERSALMATE-N-LOK2,6POS,FREEHANGING,DOUBLEROW Crimp housing Pitch4.14 mm Poles 2 x 3 MATE-N-LOK II Mini Universal, 794190-1, TE Connectivity TE Connectivity Mini-Universal MATE-N-LOK II 系列 2 行 4.14mm 节距 6 路 直 公 压接连接器外壳 06P MINI UMNL2 PLUG HSG UL94V0 |
| 分类 |
商业参数
| 产品类别 | Pin & Socket Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 500 | ||
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85366910 |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 额定电压 | 600 V | 供电电压 | 600 |
| 最大额定电流 | 9.5 A | 最小供电电压 | 600VAC |
| 连接器类型 - 电压输入 | Mini-Universal MATE-N-LOK 2 | ||
机械参数
| 颜色 | White | 深度 | 23.75mm |
| 间距 | 4.14 mm | 宽度 | 17.25mm |
| 高度 | 17.25 mm | 长度 | 18.69mm |
| 重量 | 0.0022 | 锁定类型 | Latch |
| 包装方式 | Bulk | 排间距 | 0.163" (4.14mm) |
| 触头类型 | Male or Female | 基体材料 | :Nylon |
| 外壳颜色 | White | 安装类型 | Straight |
| 连接器类型 | Plug | 紧固类型 | Latch Lock |
| 安装样式 | Free Hanging | 排数 | 2 |
| 线缆终端 | :Free Hanging | 壳体材料 | Polyamide (PA) |
| 总长度 | 18.69 mm | 包装数量 | One Piece Housing |
| 主要材料 | InterconnectSystem | 端接样式 | Crimp |
| 第一触头极性 | Pin (Male) | 触点数 | 6 |
| 接触件端接 | Crimp | 位数 | 6 |
| 中心触点材料 | 4.14 x 4.14 [.163 x .163] | 典型触点布局 | Double-Row |
| 接触镀层厚度 | 0.99 [0.039] | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | PL | 系列 | Mate-N-Lok II |
| CAD图纸 | 3D CAD Model | 制造商全称 | MATE-N-LOK |
| 产品子类型 | Receptacle Housings | 电路数 | 6 |
| 适用产品/相关产品 | Centerline Soft Shell Pin & Socket Connector | ||
环境参数
| 工作温度 | -20C to 105C | ||
