点击放大查看
745032-1
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing PL 9 POS 2.74mm Crimp ST D-Sub Standard Connectors Amplimite D-Sub Connector Standard Cable Connectors CONN PLUG 9 POS BLACK PLASTIC Conn Housing PL 9 POS 2.74mm Crimp ST Product Highlights:ConnectorProduct Series = HDJ-20Number of Positions = 9PlugWithout ContactsSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub TE Connectivity HDJ-20系列 9路 2.74mm节距 直 压接式 D-sub 连接器, 插头 9 POS AMPL HSG |
| 分类 |
商业参数
| 产品类别 | D-Sub Standard Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | RoHS Compliant | 无铅定义 | Not relevant for lead free process |
| RoHS/ELV合规状态 | RoHS compliant, ELV compliant | 材料阻燃等级 | UL 94V-2 |
机械参数
| 颜色 | Black | 深度 | 17.53 mm |
| 间距 | 2.74 mm | 宽度 | 8.23mm |
| 长度 | 19.23mm | 外形尺寸(长x宽) | 1 |
| 锁定类型 | 不带 | 包装方式 | Bulk |
| 外壳尺寸 | 1 | 方向 | 直 |
| 触点尺寸 | 20 | 触头类型 | Signal |
| 第二连接器 | Without | 外壳颜色 | Black |
| 安装类型 | Straight | 端子尺寸 | 20 |
| 连接器类型 | Plug for Male Contacts | 安装样式 | Wire |
| 排数 | 2 | 外壳材料（壳体） | Plastic |
| 连接器样式 | D-Sub | 壳体材料 | Thermoplastic |
| 总长度 | 19.23 mm | 包装数量 | 1 |
| 尺寸/外形 | 19.23 x 8.23 x 17.53mm | 接地凹痕 | Without |
| 触点数 | 9 | 介电材料 | Thermoplastic, Glass Filled |
| 位数 | 9 | 外壳尺寸-插件 | All Plastic |
| 外壳尺寸，连接器布局 | 1 (DE, E) | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 等级 | Standard | 连接器性别 | PL |
| 系列 | HDJ-20 | 产品子类型 | Connector |
