点击放大查看

5650868-4

制造商	TE Connectivity Ltd.
描述	Conn DIN 41612 RCP 48 POS 2.54mm Solder RA Thru-Hole Eurocard Type R CONN DIN RECEPT 48POS RT ANG PCB DIN 41612 Connectors RECPT 48P R/A TYPE R Conn DIN 41612 RCP 48 POS 2.54mm Solder RA Thru-Hole Product Highlights:Receptacle48 PositionsPCB Mount Angle = Right AngleNo PCB Retention FeaturePost Type = Solder PostSearch Keywords:parallel, stacking, co-planar, horizontal, high density, midplane, two piece, IEC 603-2, DIN 41612 TYPERTTRSDRTLR/A,ASSY,RECEPTACLE,EUROCARD,TYPER/2,LEAD-F 48 Position Right Angle Solder Post No PCB Retention Receptacle Eurocard Type R TE Connectivity Eurocard 系列 48 路 2.54mm 节距, R型 C2等级, 3 行 a/b/c, 直角 DIN 41612 插座, 焊接端接 ASSY,RECEPTACLE,EUROCARD,TYPE
分类	连接器解决方案背板连接器DIN 41612

对参数有疑问？问 AI 助手

商业参数

产品类别	DIN 41612 Connectors	标准包装数量	Bulk
工厂包装数量	140

合规参数

RoHS	Lead free / RoHS Compliant	无铅定义	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c
RoHS/ELV合规状态	RoHS compliant, ELV compliant	材料阻燃等级	UL 94V-0

电气参数

接口	Eurocard/DIN 41612	供电电压	250
最大额定电流	1.5	最小供电电压	250VAC

机械参数

颜色	Gray	深度	17.58 mm
间距	2.54 mm	高度	10.49 mm
涂层	Without	包装方式	Bulk
方向	直角	端接方式	Solder
触头类型	Solder Post	外壳颜色	Gray
尾部长度	2.79 mm	安装类型	Through Hole
连接器类型	Receptacle, Female Sockets	接触镀层	DIN 41612 Class 2
安装样式	Through Hole	排数	3
端子样式	.25 x .25 mm [ .01 x .01 in ]	插入件材料	铜合金
触头材料	Copper Alloy	壳体材料	Polymer
总长度	53.24 mm	面板安装类型	通孔 - 焊接
主要材料	Eurocard	端接排数	焊接
先合后断	No	端接样式	Solder Pin
配接方向	Without	触点数	48
位数	48	触头长度-柱	2.79 mm [ .11 in ]
绝缘材料 - 材质	Polymer Thermoplastic, Glass Filled	安装孔直径	不带
接触件表面处理 - 配合	锡	端子柱长度	2.79 [0.110]
接触镀层厚度	2.54 µm [ 100 µin ]

产品信息

类型	DIN 41612	等级	II
样式	1/2 R	连接器性别	RCP
系列	5650868	导向方式	Without
产品子类型	Receptacle	列数	16
插座类型与数量	A/b/c	加载位置数	All

环境参数

额定等级	C2	级别、等级	2
工作温度	-55°C ~ 125°C	封装热阻	1.57 mm [ .062 in ]
