点击放大查看
3-87499-2
| 制造商 | |
| 描述 | Conn Housing RCP 17 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 17POS .100 SINGLE Headers & Wire Housings 17 MODIV HSG COMP SR Conn Housing RCP 17 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 17Housing Type = ReceptacleNumber of Rows = SingleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 17 Position Single Row 2.54 mm Pitch Closed Ends MOD IV Receptacle Housing 17 MODIV HSG COMP SR .100CL |
| 分类 |
商业参数
| 商标名 | AMPMODU | 其他名称 | 3874992 |
| 产品类别 | Headers & Wire Housings | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 标准编号 | CSA LR7189, UL E28476 |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 额定电压 | 250 VAC | 开关功能 | Unlatched |
| 供电电压 | 250 VAC | 接触电阻 | 12 mΩ |
| 输入电阻 | 5000 | 连接器阻抗 | 压接 |
| 最大额定电流 | 3 A | 连接器类型 - 电压输入 | Crimp |
| 保护额定电压（VPR） | 750 V | ||
机械参数
| 颜色 | Black | 间距 | 2.54 mm |
| 高度 | 3.56 mm [ .14 in ] | 长度 | 43.31 mm [ 1.71 in ] |
| 锁定类型 | 不带 | 包装方式 | Bulk |
| 壳体颜色 | 黑色 | 排间距 | 2.54 mm |
| 触点形式 | Female Socket | 触头类型 | Female Socket |
| 安装类型 | Straight | 连接器类型 | Receptacle |
| 安装样式 | Free Hanging | 排数 | 1 |
| 插入件材料 | 铍铜 | 壳体材料 | Thermoplastic |
| 包装数量 | 1 | 端接样式 | Crimp |
| 第一触头极性 | Socket (Female) | 触点数 | 17 |
| 接触件端接 | Crimp | 位数 | 17 |
| 安装孔直径 | 不带 | 典型触点布局 | 同轴 |
| 静电放电屏蔽 | 不带 | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | RCP | 系列 | AMPMODU MOD IV |
| 产品子类型 | Receptacles / Sockets - Housings | 其他规格 | 否 |
| 输出配置 | Free Hanging (In-Line) | ||
环境参数
| 测试温度 | 标准部件 - 非辉光导线 | 工作温度 | - 65 C to + 105 C |
