2-1445096-3

点击放大查看

2-1445096-3

制造商
TE Connectivity Ltd.
描述Conn Power HDR 3 POS 3mm Solder ST SMD 3 Terminal 1 Port Pin & Socket Connectors HDR VERT 3 POS 30 AU SINGLE ROW 3mm Centerline, 250V, 5 A max. CONN HEADER 3MM 3POS GOLD SMD 2-1445096-3 3mm Centerline, 250V, 5 A max. Product Highlights:HeaderConnector Type = Header - PinSurface Mount Contact Termination TypeNumber of Positions = 3Number of Rows = 1Search Keywords:wire to board, wire to wire, high density, Power Pin & Socket, Soft Shell, Lighting Interconnection, wire to panel, power, pcb connectors, discrete wire, crimp, low profile, Micro MATE-N-LOK connector, MATE-N-LOK connector, Low Profile Soft Shell connector, Lighting, LED Lighting, Lighting Applications, Soft Shell connector, Low profile Micro MATE-N-LOK connector MICRO MNL HDR ASSY SINGLE ROW
分类
工具与焊接解决方案压接钳、压接机、压力机压接钳
对参数有疑问？问 AI 助手

商业参数

其他名称A33205TR标准包装规格210
产品类别Pin & Socket Connectors标准包装数量Tape & Reel
工厂包装数量1

合规参数

RoHSRoHS CompliantUL等级获得认可
零件状态E28476无铅定义Reflow solder capable to 245°C, Reflow solder capable to 260°C
CSA档案号LR7189标准编号CSA, UL
CSA分类已认证RoHS/ELV合规状态RoHS compliant, ELV compliant
UL阻燃等级UL 94V-0认证机构标志是
材料阻燃等级UL 94V-0

电气参数

额定电压250 V供电电压250
最大额定电流5 A

机械参数

颜色Black间距3 mm
宽度9.24长度13
密封型Not Sealed镀层Matte-Tin
包装方式Tape & Reel (TR)壳体颜色黑色
端接方式Solder触头类型Male Pin
极化Without外壳颜色Black
安装类型Surface Mount连接器类型Header, Shrouded
接触镀层Gold紧固类型Locking Ramp
安装样式SMD/SMT引脚数3
排数Single高度（英寸）3.86
触头材料Brass壳体材料Nylon
框架材料Phosphor Bronze安装特性压紧柱体
包装数量210面板安装类型表面贴装
端接样式Solder第一触头极性Pin (Male)
触点数3位数3
外壳尺寸-插件插头安装孔直径带有
中心触点材料3.00 [0.118]接触件表面处理 - 配合锡
典型触点布局直插式端子柱长度1.53 mm [ .06 in ]
接触镀层厚度30µin (0.76µm)静电放电屏蔽不带

产品信息

备注Vacuum pick-up button.类型Power
连接器性别HDR产品子类型Headers
应用细节Power加载位置数All

环境参数

测试温度标准件 - 非灼热丝温度额定值High
工作温度-40 – 105 °C [ -40 – 221 °F ]封装热阻.062 mm [ 1.57 in ]
