点击放大查看

1757840-4

制造商	TE Connectivity Ltd.
描述	Conn D-Subminiature SKT 37 POS Solder RA Thru-Hole 37 Terminal 1 Port D-Sub Standard Connectors AMPLIMITE R/A RCPT ASY 109 ZN 4 Subminiature D Pin/Socket Connectors for MIL-C-24308 and MIL-C-39029 AMPLIMITE,R/A RCPT ASY,109,ZN,4 AMPLIMITE,R/A RCPT ASY,109,ZN,4 Search Keywords:AMPLIMITE, rack and panel, MIL-M24519, DIN 41652, input/output, box to box, military/aerospace, d-sub, d sub, dsub
分类	连接器解决方案D-Sub连接器

对参数有疑问？问 AI 助手

商业参数

标准包装规格	6	零件号别名	M24308 M24308/23-52
标准包装数量	Bulk

合规参数

RoHS	RoHS Compliant	资质认证	No
无铅定义	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c	RoHS/ELV合规状态	RoHS compliant, ELV compliant
认证机构标志	Yes

电气参数

连接器阻抗

机械参数

直径	0.76 [0.030]	外壳尺寸	4
触点尺寸	20	非磁性	No
安装类型	Right Angle	外壳镀层	Zinc
接触镀层	Gold	安装样式	Through Hole
外壳材料（壳体）	Steel	触头材料	Brass, Beryllium Copper
端接样式	Through Hole	触点数	37
位数	37	衬套/护套类型	No
安装孔直径	2.92-3.18 [.115-.125]	端子柱长度	4.78 [0.188]

产品信息

连接器性别	Receptacle	系列	109
密度	Standard	插座类型	With
制造商全称	Tyco Electronics	产品子类型	Connector
连接类型	Printed Circuit Board	设备部件号	M24308/23-52
