1586105-3
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing RCP 3 POS 4.2mm ST VAL-U-LOK Series Connector System CONN RCPT HOUSING 3POS SGL 4.2MM 3w s/r receptacle housing Pin & Socket Connectors 3P RCPT SR V2 Conn Housing RCP 3 POS 4.2mm ST Product Highlights:HousingReceptacleNumber of Circuits = 3UL 94V-2Number of Rows = SingleSearch Keywords:wire to wire, wire to board, soft shell, Power Pin & Socket, NIC, Network Interface Cards, PC Cards, Cabled Power, pcb connectors, discrete wire, crimp, Power Economy, Molex Mini-Fit Jr, VAL-U-LOK, 4.2mm, PE, PE Series Connector System, .165 Centerline PE, Valulok, PWRSIGALLP Conne RECEPTACLE,HOUSING,VAL-U-LOK,3POS,SINGLEROW,UL94V-2 Female crimp housing Pitch4.2 mm Poles 1 x 3 VAL-U-LOK, 1586105-3, TE Connectivity TE Connectivity VAL-U-LOK 系列 4.2mm 节距 3 路 直 母 压接连接器外壳 3P RCPT VAL-U-LOK SR V2 |
| 分类 |
商业参数
| 产品类别 | Pin & Socket Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 1000 | ||
合规参数
| RoHS | Not applicable / RoHS Compliant | 海关税号 | 85369010 |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-2 | ||
电气参数
| 最大额定电流 | 9 A | 最小供电电压 | 600VAC |
机械参数
| 颜色 | Natural | 深度 | 20.6mm |
| 间距 | 4.2 mm | 长度 | 13.8mm |
| 重量 | 0.000001 | 材料（通用） | Nylon |
| 包装方式 | Bulk | 排间距 | 0.165" (4.20mm) |
| 触头类型 | Female Socket | 外壳颜色 | Natural |
| 安装类型 | Straight | 连接器类型 | Receptacle |
| 接触镀层 | Tin, Gold | 紧固类型 | Latch Lock |
| 安装样式 | Free Hanging | 排数 | 1 |
| 触头材料 | Brass, Phosphor Bronze | 壳体材料 | Nylon |
| 总长度 | 13.8 mm | 主要材料 | InterconnectSystem |
| 端接样式 | Crimp | 第一触头极性 | Socket (Female) |
| 触点数 | 3 | 接触件端接 | Crimp |
| 位数 | 3 | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | RCP | 系列 | PE |
| CAD图纸 | 3D CAD Model | 制造商全称 | VAL-U-LOK |
| 产品子类型 | Housing | 电路数 | 3 |
| 适用产品/相关产品 | Wire-to-Board Connector, Wire-to-Panel Connector, Wire-to-Wire Connector | ||
