E3FSC
| 制造商 | |
| 描述 | XLR Connectors E SERIES SOLDER CUP Conn Audio F 3 POS Solder Cup ST Panel Mount 4 Terminal 1 Port CONN PLUG 3POS FMAL SLV SOLDER QG receptacle CONNECTOR, XLR, JACK, 3POS QGreceptacle |
| 分类 |
商业参数
| 产品类别 | XLR Connectors | 标准包装数量 | 1 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 海关税号 | 85366990 | ||
电气参数
| 额定电压 | 125 V | 供电电压 | Standard XLR |
| 最大额定电流 | 15A | ||
机械参数
| 深度 | 35.3 | 高度 | 31 |
| 重量 | 0 | 包装方式 | Bulk |
| 方向 | Keyed | 端接方式 | Solder Cup |
| 安装类型 | Panel Mount | 外壳镀层 | Nickel |
| 连接器类型 | Plug, Female Sockets | 接触镀层 | Silver |
| 紧固类型 | Latch Lock | 安装样式 | Chassis (Panel) |
| 本体材料 | :Metal | 触头材料 | Copper Alloy |
| 壳体材料 | Thermoplastic | 总长度 | 26 |
| 端接样式 | Solder | 触点数 | 3 |
| 接触件端接 | :Solder | 位数 | 3 |
| 外壳尺寸-插件 | XLR | 外壳材料及表面处理 | Die Cast, Nickel Plated |
| 第一连接器安装类型 | :Panel | ||
产品信息
| 类型 | Audio | 连接器性别 | F |
| 系列 | E | 产品特性 | Shielded |
| 产品子类型 | Connectors | 端口数 | 1 |
环境参数
| 工作温度 | -55°C ~ 85°C | ||
