UTP02235S
| 制造商 | SOURIAU SAS |
| 描述 | Standard Circular Connector 35P Sckt Receptacle Wall Mount Size 22 CONN RCPT FEMALE 35POS WALL MNT Conn CPC SKT 35 POS ST Wall Mount 35 Terminal 1 Port CIRCULAR CONN, RECEPTACLE, 35 WAY, PANEL connector,plasticcircular,wallreceptacle,size22,for35size16socketcontact |
| 分类 |
商业参数
| 商标名 | Trim Trio | 其他名称 | SOU1151 |
| 产品类别 | Standard Circular Connector | 标准包装数量 | 25 |
| 工厂包装数量 | 25 | ||
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85369010 |
| 材料阻燃等级 | :UL94V-0 | ||
电气参数
| 绝缘电阻 | :5000Mohm | ||
机械参数
| 重量 | 0.023 | 包装方式 | Bulk |
| 外壳尺寸 | 22 | 方向 | Keyed |
| 外壳样式 | Square Flange | 触点尺寸 | 16 |
| 触头类型 | Crimp | 安装类型 | Panel Mount, Flange |
| 连接器类型 | Receptacle for Female Contacts | 紧固类型 | Bayonet Lock |
| 安装样式 | Panel | 外壳材料（壳体） | Thermoplastic |
| 插入角度 | :22-35 | 本体材料 | :Glass Filled Thermoplastic |
| 第一触头极性 | Without Socket Contacts | 连接器颜色 | :Black |
| 触点数 | 35 | 位数 | 35 |
| 外壳尺寸-插件 | 22-35 | 外壳材料及表面处理 | Thermoplastic, Glass Filled |
| 第一连接器安装类型 | :Panel | ||
产品信息
| 备注 | Contacts Not Provided | 连接器性别 | :Receptacle |
| 系列 | UTP | 产品子类型 | Receptacles |
环境参数
| 防护等级 | IP65 - Dust Tight, Water Resistant | 工作温度 | :125°C |
