HTSW-110-08-G-D-RA

制造商	Samtec, Inc.
描述	Conn Unshrouded Header HDR 20 POS 2.54mm Solder RA Thru-Hole CONN HDR 20 POS 2.54MM R/A HEADER, 2.54MM, THT, R/A, 20WAY
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

其他名称

Q4195579A

标准包装数量

Bulk

合规参数

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
欧盟RoHS	Compliant	海关税号	85366930

电气参数

最大额定电流

7.6/Contact

最小输入电压

450VAC

机械参数

颜色	Natural	深度	12.44
间距	2.54 mm	高度	6.1
重量	0.0121	包装方式	Tube
排间距	0.100" (2.54mm)	端接方式	Solder
触头类型	Male Pin	柱间距	:2.54mm
外壳颜色	Natural	安装类型	Right Angle
连接器类型	Header, Unshrouded	接触镀层	Gold Over Nickel
排数	2	触头材料	Phosphor Bronze
壳体材料	Liquid Crystal Polymer	总长度	25.4
触点数	20	接触件端接	:Through Hole Right Angle
位数	20	接触长度 - 配合	0.230" (5.84mm)
接触镀层厚度	10µin (0.25µm)

产品信息

类型	Unshrouded Header	连接器性别	HDR
系列	:HTSW	加载位置数	All

文档与媒体

PDF 文档

htsw_th.pdf

PDF 文档

TSW, HTSW Series Spec Sheet

PDF 文档

TSW_TH.PDF
