点击放大查看
3033090
| 制造商 | |
| 描述 | DIN Rail Terminal Blocks UKN 16 BU Misc Products CONN TERM BLOCK Neutral conductor disconnect terminal blocks UKN 16 BU UKN16BU Phoenix Contact UKN 系列 蓝色 断开接线排 , 57A, 400 V |
| 分类 |
商业参数
| 产品 | DIN Rail Terminal Blocks | 商标名 | CLIPLINE UK |
| 其他名称 | UKN 16 BU | 产品类别 | DIN Rail Terminal Blocks |
| 标准包装数量 | 1 | 工厂包装数量 | 1 |
合规参数
| RoHS | RoHS Compliant | 欧盟RoHS | Compliant |
| 材料阻燃等级 | UL94 V-2 | ||
电气参数
| 电流 - IEC | 57A | IEC电压 | 400V |
| 额定电压 | 400 V | 最大额定电流 | 57A |
机械参数
| 颜色 | 蓝色 | 长度 | 1.717" (43.61mm) |
| 重量 | 0.826116 oz | 高度（最大） | 2.421" (61.50mm) |
| 外壳颜色 | Blue | 安装类型 | DIN Rail |
| 剥线长度（范围） | 11mm | 端子宽度 | 10.2mm |
| 端接排数 | 混合 | 端接样式 | Special, Hybrid |
| 位数 | 2 | 绝缘材料 - 材质 | Polyamide (PA), Nylon |
| 线规或范围 - AWG | 6-20 AWG | 线规或范围 - mm² | 0.5-16mm² |
产品信息
| 类型 | Bus Bar - Side | 系列 | UK |
| 叠层数 | 单层 | 层数 | 1 |
