点击放大查看
1773336
| 制造商 | Phoenix Contact GmbH & Co. KG |
| 描述 | Circular Metric Connectors HC-HV 3-ESTC Conn HEAVYCON Insert M 3 POS Crimp ST Panel Mount INSERT MALE 3+2POS+1GND CRIMP HC-HV3-ESTC Phoenix Contact 5P+E 公插 RJ45-Rangierfeld , 额定电流 16A/ 250 V |
| 分类 |
商业参数
| 交货时间 | 24 Days | 商标名 | HEAVYCON |
| 其他名称 | HC-HV 3-ESTC | 子类别 | Connector Rectangular |
| 产品类别 | Circular Metric Connectors | 标准包装数量 | 1 |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 材料阻燃等级 | UL94 V-0 | ||
电气参数
| 额定电压 | 250 V | 最大额定电流 | 16A |
| 最小输入电压 | 690V | ||
机械参数
| 尺寸 | B10 | 重量 | 1.868462 oz |
| 包装方式 | Bulk | 端接方式 | Crimp |
| 触头类型 | CK 2.5-ED | 安装类型 | Straight |
| 连接器类型 | Insert without Contacts | 接触镀层 | Silver |
| 排数 | 2 | 触头材料 | Copper Alloy |
| 壳体材料 | Polyamide | 端接样式 | Crimp |
| 第一触头极性 | M | 触点数 | 3 |
| 位数 | 3+2+Ground | ||
产品信息
| 类型 | HEAVYCON Insert | 连接器性别 | Male |
| 极性 | 5P+E | 附件类型 | 触点插件 |
| 行业别名 | HC-HV 3-ESTC | ||
环境参数
| 工作温度 | -40°C ~ 125°C | ||
