P8-56R-Q

制造商	Panduit Corp.
描述	Ring Tongue Terminal 8AWG 31.75mm 14.99mm Tin Terminals 5/16 8AWG RING TERM RING TERM NON INS 8AWG
分类	连接器解决方案压接与焊接端子/接头压接端子（通用）

对参数有疑问？问 AI 助手

商业参数

产品	Ring Terminals	产品类别	Terminals
标准包装数量	Bulk	工厂包装数量	25

合规参数

RoHS

RoHS Compliant

欧盟RoHS

Compliant

机械参数

深度	14.99	长度	1.25 in
重量	3.200000 oz	镀层	Tin
包装方式	Bulk	厚度	0.040" (1.02mm)
绝缘类型	Not Insulated	导线线规	8 AWG
端接方式	Crimp	基体材料	Copper
安装类型	Free Hanging (In-Line)	螺柱/焊片尺寸	7.93 mm
端子类型	Circular	接触镀层	Tin
触头材料	Copper	总长度	1.250" (31.75mm)
端接样式	Wire	绝缘直径	0.280" (7.11mm)
绝缘材料 - 类型	Non-Insulated	外缘宽度	0.590" (14.99mm)

产品信息

类型	Ring Tongue Terminal	连接器性别	Female
系列	P8	产品特性	Brazed Seam

文档与媒体

PDF 文档

076602.pdf

PDF 文档

P8-xR(N) Drawing

PDF 文档

A4121505.pdf
