PIC24HJ64GP502-I/SO
| 制造商 | Microchip Technology Inc. |
| 描述 | MCU 16-bit PIC24 PIC RISC 64KB Flash 3.3V 28-Pin SOIC W Tube 16-bit MCU, 64KB Flash,CAN,DMA,40 MI IC MCU 16BIT 64KB FLASH 28SOIC PIC24HJ64GP502-I/SO, 16 bit Microcontroller PIC 40MIPS 64kb Flash, 8kb RAM, I2C SPI 28-Pin SOIC 16-bit Microcontrollers - MCU 16B MCU 28LD64KB DMA 40MIPS MCU, 16BIT, 64K FLASH, 40MIPS, 28SOIC IC,PIC24HJ64GP502-I/SO Microchip PIC24HJ 系列 16 bit PIC MCU, 40MIPS, 64 kB ROM 闪存, 8 kB RAM, 28针 SOIC封装 PIC24HJ 64K QFN28 85°C |
| 分类 |
商业参数
| 最小起订量 | 150 | 单位包装 | 27 |
| 其他名称 | PIC24HJ64GP502ISO | 产品类别 | 16-bit Microcontrollers - MCU |
| 标准包装数量 | Rail / Tube | 工厂包装数量 | 27 |
合规参数
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85423190 | ||
电气参数
| 转速 | 40 MHz | 定时器 | 5 x 16 bit |
| RAM 大小 | 8 KB | 内核大小 | 16-Bit |
| 核心类型 | PIC | 接口 | CAN/I2C/SPI/UART |
| 时钟速率 | 40 MHz | 分辨率 | 16bit |
| 存储器容量 | 8 KB | 存储器类型 | :Flash |
| I/O 数量 | 21 | 位数 | :16 |
| 额定电压 | 3 → 3.6 V | 看门狗定时器 | 1 |
| 时钟频率 | :80MHz | 数据转换器 | A/D 10x10b/12b |
| FPGA 核心单元数 | :40 | 最大频率 | 40MIPS |
| DAC数量 | 4 | 振荡器类型 | Internal |
| 供电电压 | 3.3 V | 分辨率（位） | 10 bit, 12 bit |
| 通道数量 | 1 | 程序存储器大小 | 64 KB |
| 程序存储器类型 | Flash | ADC/DAC 数量 | 10 |
| 频率（中心/带宽） | 16bit | 每元件位数 | 10 bit, 12 bit |
| 供电电压 (Vcc/Vdd) | 3 V ~ 3.6 V | ||
机械参数
| 宽度 | 7.5mm | 高度 | 2.35mm |
| 长度 | 17.9mm | 重量 | 0.002963 |
| 包装方式 | Tube | 端接方式 | :SMD |
| 安装类型 | Surface Mount | 安装样式 | SMD/SMT |
| 引脚数 | :28 | 封装形式 | 28SOIC W |
| 冷却的封装 | SOIC | 材料表面处理 | :MSL 1 - Unlimited |
| 尺寸/外形 | 17.9 x 7.5 x 2.35mm | 位数 | 28 |
| 供应商器件封装 | 28-SOIC | 核心数/总线宽度 | 16 Bit |
| 脉冲宽度失真（最大） | 4(16 bit) | ||
产品信息
| USB | 0 | 系列 | PIC24H |
| 产品特性 | CAN Controller | 闪存大小 | :64KB |
| 片内RAM（通道数×位宽） | 10-chx10-bit|10-chx12-bit | 外设 | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| 架构 | RISC | 连接性 | CAN, I²C, IrDA, LIN, PMP, SPI, UART/USART |
| 核心处理器 | PIC | 定时器数量 | 5 |
| 控制器系列 | :PIC24HJxxGPxxx | 射频系列/标准 | PIC24 |
| A/D转换器数量 | :10 | ||
环境参数
| 工作温度 | -40 to 85 °C | ||
