点击放大查看
630-0510
| 制造商 | |
| 描述 | DIN Connectors SCKT 5C 60 DEG NKL SOCKET, DIN, FLANGED, 240DEG, 5POLE Socket; DIN; female; PIN:5; Pin layout:240°; soldering; 34V; 10mΩ Female panel connector nickel-plated 5P 5 'C', 630-0510, Deltron Components |
| 分类 |
商业参数
| 产品类别 | DIN Connectors | ||
合规参数
| RoHS | In Transition | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | ||
电气参数
| 额定电压 | 100 V | 供电电压 | DIN |
| 接触电阻 | :10mohm | 最大额定电流 | 4 A |
机械参数
| 长度 | :13.4mm | 重量 | 0.008 |
| 材料（通用） | :Diecast, Nickel Plated | 安装类型 | soldering |
| 行程角度 | 240 | 连接器类型 | :Audio, DIN |
| 接触镀层 | Silver | 安装样式 | Chassis (Panel) |
| 本体材料 | :- | 材料表面处理 | nickel plated |
| 触头材料 | Brass | 包装数量 | 100 |
| 连接器 - 电缆 | socket | 端接样式 | Solder Lug |
| 连接器颜色 | :Nickel | 触点数 | 5 |
| 面板开孔形状 | :16mm | 接触件端接 | :Solder |
| 位数 | 5 | 触点材料 - 镀层 | silver plated |
| 第一连接器安装类型 | :Panel | 第一连接器安装特征 | 240° |
产品信息
| SPG | 100 | 连接器性别 | Female |
| 系列 | :- | 单元数量 | 1 |
环境参数
| 工作温度 | :70°C | ||
