点击放大查看

16282-3PG-311

制造商	Switchcraft, Inc.
描述	Standard Circular Connector 3P PIN CABLE END O.D.=.09-.14 Conn Field Installable PIN 3 POS Solder ST Cable Mount 3 Terminal 1 Port Standard Circular Connectors 3P PIN CABLE END O.D.=.09-.14 CONN PLUG 3POS CABLE PIN CircularCableconnector,Micro-ConCableEnd,20,SolderCup,3Contacts Switchcraft MICRO-CON-X 系列 3路电缆安装直向连接器插头 , 公触点, 嵌入式接合
分类	连接器解决方案圆形连接器标准圆形连接器

对参数有疑问？问 AI 助手

商业参数

商标名	Micro-Con-X	产品类别	Standard Circular Connector
标准包装数量	25	工厂包装数量	25

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Compliant

电气参数

额定电压

600V

最大额定电流

7.5A

机械参数

外形尺寸(长x宽)	13.5mm	直径	13.5
包装方式	Bulk	出线方向	No
方向	Keyed	外壳样式	Plug
端接方式	Solder	触头类型	3Signal
安装类型	Cable Mount	连接器类型	Plug, Male Pins
接触镀层	Gold Over Nickel	紧固类型	Bayonet Lock
触头材料	Brass	壳体材料	尼龙
总长度	32.8	端接排数	焊接
第一触头极性	PIN	触点数	3
位数	3	外壳材料及表面处理	Thermoplastic

产品信息

类型	Field Installable	系列	Micro-Con-X
产品子类型	Connectors

环境参数

防护等级

Weathertight

工作温度

-40°C ~ 75°C

文档与媒体

PDF 文档

Cable Assemblies/Connector Catalog

在线文档

ProductSummary.aspx?Parent=479
