13380-10SG-326

制造商	Switchcraft, Inc.
描述	Standard Circular Connector MAXI-CON CABLE #16 CRIMP Conn Field Installable SKT 10 POS Crimp ST Cable Mount 10 Terminal 1 Port Standard Circular Connectors MAXI-CON CABLE #16 CRIMP CONN PLUG 10POS CABLE SKT MAXI-CONCABLE#16CRIMP
分类	连接器解决方案圆形连接器标准圆形连接器

对参数有疑问？问 AI 助手

商业参数

商标名	Maxi-Con-X	标准包装数量	25
工厂包装数量	25

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Supplier Unconfirmed

电气参数

额定电压

600V

最大额定电流

1.35 A to 23 A

机械参数

直径	26.9	包装方式	Bulk
出线方向	No	导线线规	18-16
方向	Keyed	端接方式	Crimp
触头类型	10Signal	安装类型	Cable Mount
连接器类型	Plug, Female Sockets	接触镀层	Gold Over Nickel
紧固类型	Bayonet Lock	安装样式	Wire
触头材料	Brass	总长度	63.5
端接样式	Crimp	第一触头极性	SKT
触点数	10	位数	10
外壳材料及表面处理	Nylon

产品信息

类型	Field Installable	系列	Maxi-Con-X
产品特性	Cable Clamp	产品子类型	Connectors

环境参数

防护等级

Weathertight

工作温度

-40°C ~ 115°C

文档与媒体

PDF 文档

Maxi-Con-X Connectors

PDF 文档

Cable Assemblies/Connector Catalog

相关型号

357-124

Conxall / Switchcraft

Standard Circular Connector TURRET LOCATOR SIZE 12,16 & 20 Assembly Tools Turret Locator-Size 12,16 And 20 TURRET LOCATOR-SIZE 1216 & 20

¥1330.0963

详情

14382-10PG-300
