点击放大查看

9120-4500PL

制造商	3M Company
描述	Conn Board to Board SKT 20 POS 2.54mm Solder ST Thru-Hole .100" Ã .100" Centerbump Polarization with Straight Solder Tails, 20 - 64 contacts CONN SOCKET 20POS .100" STR GOLD Polarized Boardmount Socket (20 pos) .100 centerline straight solder tails Headers & Wire Housings 20P STRT PLRZD SKT SOCKET, PCB, 20WAY PolarizedBoardmountSocket(20pos).100centerlinestraightsoldertails
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

零件号别名	54745226295 JE150318838	产品类别	Headers & Wire Housings
标准包装数量	Bulk	工厂包装数量	100

合规参数

RoHS

Lead free / Vendor undefined

海关税号

85369010

电气参数

最大额定电流

:1A

机械参数

颜色	Gray	间距	2.54 mm
重量	0.01	包装方式	Bulk
排间距	0.100" (2.54mm)	端接方式	Solder
触头类型	Female Socket	引脚间距	:2.54mm
安装类型	Through Hole	连接器类型	Receptacle
接触镀层	Gold Over Nickel	排数	2
触头材料	:Copper	端接样式	Through Hole
第一触头极性	Socket (Female)	触点数	20
接触件端接	:Through Hole Vertical	位数	20
接触镀层厚度	12µin (0.30µm)

产品信息

类型	Board to Board	连接器性别	SKT
系列	9100	产品特性	Polarizing Key
产品子类型	Receptacles / Sockets - PCB	加载位置数	All

环境参数

工作温度

:105°C

文档与媒体

在线文档

91xx-4500PL

PDF 文档

95058.pdf
