SSB-LX02 optoelectronic 系列
Lumex, Inc.多色LED组件，适用于照明和显示应用
Lumex, Inc. 的 SSB-LX02 系列由多种颜色的 LED 组成，适用于各种照明和显示应用，提供了灵活多变的解决方案。这些 LED 提供多种颜色选择，使其非常适合创建动态照明效果或多彩显示。如果您正在从事需要可定制颜色选项的项目，例如数字标牌、装饰照明或汽车内饰照明，这些 LED 将是一个很好的选择。
值得注意的是，它们在调色方面具有很高的灵活性。当工程师需要能够轻松切换不同色调的 LED 而不需要为每种颜色配备外部电路时，往往会选用这一系列。这使得它们特别适合空间有限或需要快速改变颜色的应用场景。
另一个实用的优势是其高亮度和良好的效率。这些 LED 设计用于提供明亮鲜艳的颜色同时保持相对较低的功耗，这对于电池供电设备或对能源效率有要求的应用至关重要。总体而言，SSB-LX02 系列提供了丰富的功能，使其成为那些希望为其项目添加色彩丰富、灵活的照明解决方案的理想选择。
系列图片（13 张）
文档与媒体
常见问答
SSB-LX02 optoelectronic - 型号列表
共 8 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 产品 | 标准包装数量 | 工厂包装数量 | RoHS | 电流 | 额定电压 | 峰值波长 | 毫坎德拉等级 | 颜色 | 包装方式 | 安装类型 | 配置 | 视角 | 透镜类型 | 额定功率 | LED正向电流 | LED正向电压 | 主波长 | 总长度 | 照明颜色 | 光通量 @ 电流/温度 | 机械寿命 | SVHC | 海关税号 | 直流正向电流（If）（最大） | 重量 | LED颜色 | LED数量 | 显示尺寸 | 标准包装规格 | 最大额定电流 | 平均球面烛光（MSCP） | 透镜样式/尺寸 | 每IC通道数 | 输出配置 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LED Bars and Arrays 9mm x 2mm Red LED SIDE LOOK 2CHIP SUPR RED CLR LED Uni-Color Red 660nm 2-Pin LIGHT BAR, RED, 2 LED, 50MCD LED Lumex | 1023 | 1: ¥7.208 | LED Bars and Arrays | LED Light Bars | 1,000 | 500 | RoHS Compliant | 30mA | 3.6V | 660nm | 50mcd | Red (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | 160° | Clear | 100 mW | 20 mA | 3.6 V | 660 nm | 9 mm | Red | 50 mcd | - | :No SVHC (20-Jun-2013) | 85312020 | :20mA | 0.002 | :Bar | :2 | :9mm x 2mm | - | - | - | - | - | - |
 LED Bars and Arrays 2 Chip LCD Illum. Yellow Clear Lens LED SIDE LOOKER 2CHIP YELLOW CLR Lumex | 3775 | 1: ¥12.716 | LED Bars and Arrays | LED Light Bars | 10 | 10 | RoHS Compliant | 30mA | 4.5V | 585nm | 10mcd | Yellow (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | - | - | 100 mW | 10 mA | 4.5 V | 585 nm | 9 mm | Yellow | 10 mcd | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Bars and Arrays 9mm x 2mm Green LED SIDE LOOKER 2-CHIP GREEN CLR LED Uni-Color Green 565nm 2-Pin LIGHT BAR, GREEN, 2 LED, 10MCD Lumex | 197 | 1: ¥5.236 | LED Bars and Arrays | LED Light Bars | 1,000 | 10 | RoHS Compliant | 25mA | 4.4V | 565nm | 10mcd | Green (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | 160° | Clear | 105 mW | 20 mA | 4.4 V | 565 nm | 9 mm | Green | 10 mcd | - | :No SVHC (20-Jun-2013) | 85312020 | :20mA | 0.002 | :Bar | :2 | :9mm x 2mm | - | - | - | - | - | - |
 | 50 | 5000: ¥3.196 | LED Bars and Arrays | LED Light Bars | - | 100 | RoHS Compliant | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | New Product: New from this manufacturer. | - | - | - | - | - | - | - | 1,000 | - | - | - | - | - |
LED Bars and Arrays 2-Chip LCD Illumin Amb 610nm Trnsp Lens LED 9MM 610NM AMB TRANSP SFIRE Lumex | 10 | 3790: ¥3.6856 | LED Bars and Arrays | LED Light Bars | 500 | 100 | RoHS Compliant | 30mA | 4V | 610nm | 15mcd | Amber (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | 160° | Tinted | - | - | - | - | - | - | - | New Product: New from this manufacturer. | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Bars and Arrays 2-Chip LCD Illumin Ylw 590nm Trnsp Lens LED 9MM 585NM SYLW TRANSP SFIRE Lumex | 10 | 5000: ¥5.8072 | LED Bars and Arrays | LED Light Bars | 500 | 100 | RoHS Compliant | 30mA | 4.2V | 590nm | 170mcd | Yellow (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | 160° | Tinted | - | - | - | - | - | - | - | New Product: New from this manufacturer. | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Bars and Arrays 2 Chip LCD Illum. Red Clear Lens LED SIDE LOOKER 2-CHIP RED CLR LED Uni-Color Red 635nm 2-Pin Lumex | 205 | 5000: ¥3.74 | LED Bars and Arrays | LED Light Bars | 100 | 100 | RoHS Compliant | 30mA | 4.5V | 635nm | 16mcd | Red (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 10 | 5000: ¥2.1964 | - | - | 100 | - | - | 25mA | 4.4V | 565nm | 10mcd | Green (x 2) | Bulk | Through Hole, Right Angle | 1 high x 2 wide | 160° | Tinted | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 25mA | 10mcd | 160° | 1 high x 2 wide | Through Hole, Right Angle |
