Würth Elektronik GmbH & Co. KG- D-Sub连接器

伍尔特电子（Würth Elektronik）是全球知名的电子和机电元件制造商，隶属于伍尔特集团，成立于1945年，总部位于德国尼登哈尔。公司专注于EMC和感性元件领域，核心产品包括铁氧体、铁氧体磁珠、电感器、共模扼流圈、变压器和连接器等。通过其MIDCOM部门，伍尔特电子依托遍布全球的ISO认证生产基地和配送中心，服务多元市场。产品线还涵盖PCB装配方案、无线连接模块以及电容、电阻等无源元件。公司秉承“比你更期待”的理念，为客户提供从设计导入到原型开发直至批量生产的强大工程支持。全球120多名技术销售人员确保及时、本地化的服务，同时提供免费设计样品。凭借高质量制造和持续创新，伍尔特电子在EMC元件市场占据重要地位。其元件广泛应用于汽车电子、工业自动化、消费电子和电信基础设施。可靠性的承诺和完善的技术文档，使伍尔特电子成为全球工程师值得信赖的合作伙伴。

D-Sub连接器 - 型号列表

共 26 个型号

制造商零件编号	库存	价格	RoHS	SVHC	海关税号	量程（°/s）	额定电压	最大额定电流	深度	间距	宽度	高度	长度	重量	包装方式	绝缘类型	外壳尺寸	触头类型	安装类型	外壳镀层	接触镀层	排数	外壳材料（壳体）	触头材料	壳体材料	尺寸/外形	端接样式	触点数	接触件端接	绝缘材料 - 类型	连接器性别	系列	插拔次数	工作温度
4 61802525123 25 way female PCB D-sub Connector D-Sub Standard Connectors WR-DSUB Connector 25P Female PCB SOCKET, D-SUB, PCB, 25WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 25 路直向通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	11	1: ¥24.234	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.7mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.04mm	0.0001	Tray	Insulated	:DB	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	53.04 x 12.5 x 10.7mm	SMD	25	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618015231121 8.08mm 15 way 90deg D-sub PCB Socket D-Sub Standard Connectors WR-DSUB Female Angled PCB 15 pins SOCKET, D-SUB, PCB, R/A, 15WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 15 路直角通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	1437	1: ¥27.676	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac	3A	18.5mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.2mm	0.01094	Tray	Insulated	:DA	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	39.2 x 12.5 x 18.5mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 61800925123 9 way female PCB D-sub Connector D-Sub Standard Connectors WR-DSUB Connector 9P Female PCB SOCKET, D-SUB, PCB, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路直向通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	10	1: ¥22.2915	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.7mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.81mm	0.00479	Tray	Insulated	:DE	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	30.81 x 12.5 x 10.7mm	SMD	9	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618025231421 10.3mm 25w Header 90deg D-sub Connector D-Sub Standard Connectors WR-DSUB Male Angled PCB Connector 25 PLUG, D-SUB, PCB, R/A, 25WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 25 路直角通孔安装 PCB D-sub 连接器插头 Wurth Elektronik	100	1: ¥44.8903	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac/dc	3A	20.5mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.1mm	0.01514	Tray	Insulated	:DB	Stamped / Formed Contacts	Right Angle	Tin	Gold	2	Steel	Copper Alloy	Steel	53.1 x 12.5 x 20.5mm	SMD	25	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 61801525123 15 way female PCB D-sub Connector D-Sub Standard Connectors WR-DSUB Connector 15P Female PCB SOCKET, D-SUB, PCB, 15WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 15 路直向通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	14	1: ¥22.78	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.7mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.14mm	0.00709	Tray	Insulated	:DA	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	39.14 x 12.5 x 10.7mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618025231221 8.08mm 25w Header 90deg D-sub Connector D-Sub Standard Connectors WR-DSUB Male Angled PCB Connector 25 PLUG, D-SUB, PCB, R/A, 25WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 25 路直角通孔安装 PCB D-sub 连接器插头 Wurth Elektronik	16	1: ¥39.5304	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac	3A	18.5mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.1mm	0.0138	Tray	Insulated	:DB	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	53.1 x 12.5 x 18.5mm	SMD	25	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 618009231121 8.08mm 9 way 90deg D-sub PCB Socket D-Sub Standard Connectors WR-DSUB Female Angled PCB 9 pins SOCKET, D-SUB, PCB, R/A, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路直角通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	10	1: ¥19.047	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac	3A	18.5mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.8mm	0.00851	Tray	Insulated	:DE	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	30.8 x 12.5 x 18.5mm	SMD	9	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618015231321 10.3mm 15 way 90deg D-sub PCB Socket D-Sub Standard Connectors WR-DSUB Female Angled PCB 15 pins SOCKET, D-SUB, PCB, R/A, 15WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 15 路直角通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	284	1: ¥36.9642	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac/dc	3A	20.75mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.2mm	0.01284	Tray	Insulated	:DA	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	39.2 x 12.5 x 20.75mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 61802525023 25 way male PCB D-sub Connector D-Sub Standard Connectors WR-DSUB Connector 25P Male PCB PLUG, D-SUB, PCB, 25WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 25 路直向通孔安装 PCB D-sub 连接器插头 Wurth Elektronik	24	1: ¥30.7125	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.9mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.04mm	0.0001	Tray	Insulated	:DB	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	53.04 x 12.5 x 10.9mm	SMD	25	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 618009231421 10.3mm 9w Header 90deg D-sub Connector D-Sub Standard Connectors WR-DSUB Male Angled PCB Connector 9p PLUG, D-SUB, PCB, R/A, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路直角通孔安装 PCB D-sub 连接器插头 Wurth Elektronik	364	1: ¥26.3809	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac/dc	3A	20.75mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.8mm	0.00878	Tray	Insulated	:DE	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	30.8 x 12.5 x 20.75mm	SMD	9	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 618015227221 15 way female D-sub IDC Connector D-Sub Standard Connectors WR-DSUB Female 15p IDC connector SOCKET, D-SUB, IDC, UNC 4-40, 15WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 15 路 IDC D-sub 连接器, 插座, 钢外壳 Wurth Elektronik	160	1: ¥56.9296	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - IDC Dsub	250 V ac	3A	17.25mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.2mm	0.00954	Tray	Insulated	:DA	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	39.2 x 12.5 x 17.25mm	SMD	15	:IDC / IDT	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618009227221 9 way female D-sub IDC Connector D-Sub Standard Connectors WR-DSUB Female 09p IDC connector SOCKET, D-SUB, IDC, UNC 4-40, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路 IDC D-sub 连接器, 插座, 钢外壳 Wurth Elektronik	157	1: ¥51.7426	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - IDC Dsub	250 V ac	3A	17.25mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.8mm	0.00719	Tray	Insulated	:DE	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	30.8 x 12.5 x 17.25mm	SMD	9	:IDC / IDT	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618015330923 15w female high density D-sub Connector D-Sub Standard Connectors WR-DSUB Female High Density Angled 15p SOCKET, HD D-SUB, R/A, PCB, 15WAY Wurth Elektronik 618 系列 2.54 mm, 5.08 mm 节距 15 路直角通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	683	1: ¥25.8713	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac/dc	3A	21.1mm	2.54 mm, 5.08 mm	12.5mm	12.5 mm	30.8mm	0.00988	Tray	Insulated	:DA	Stamped / Formed Contacts	Right Angle	Nickel	Gold	3	Steel	Copper Alloy	Steel	30.8 x 12.5 x 21.1mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 61800925023 9 way male PCB D-sub Connector D-Sub Standard Connectors WR-DSUB Connector 9P Male PCB PLUG, D-SUB, PCB, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路直向通孔安装 PCB D-sub 连接器插头 Wurth Elektronik	54	1: ¥19.8471	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.9mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.81mm	0.00432	Tray	Insulated	:DE	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	30.81 x 12.5 x 10.9mm	SMD	9	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
3 618015231221 8.08mm 15w Header 90deg D-sub Connector D-Sub Standard Connectors WR-DSUB Male Angled PCB Connector 15 PLUG, D-SUB, PCB, R/A, 15WAY Wurth Elektronik	221	1: ¥31.668	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac	3A	18.5mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.2mm	0.01	Tray	Insulated	:DA	Stamped / Formed Contacts	Right Angle	Nickel	Gold	2	Steel	Copper Alloy	Steel	39.2 x 12.5 x 18.5mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 618015226221 15 way male D-sub IDC Connector D-Sub Standard Connectors WR-DSUB Male 15p IDC connector PLUG, D-SUB, IDC, UNC 4-40, 15WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 15 路 IDC D-sub 连接器, 插头, 钢外壳 Wurth Elektronik	129	1: ¥33.306	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - IDC Dsub	250 V ac	3A	17.25mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.2mm	0.00945	Tray	Insulated	:DA	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	39.2 x 12.5 x 17.25mm	SMD	15	:IDC / IDT	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 618009231321 10.3mm 9 way 90deg D-sub PCB Socket D-Sub Standard Connectors WR-DSUB Female Angled PCB 9 pins SOCKET, D-SUB, PCB, R/A, 9WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 9 路直角通孔安装 PCB D-sub 连接器插座 Wurth Elektronik	1097	1: ¥23.052	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A PCB Mount Dsub	125 V ac/dc	3A	20.75mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	30.8mm	0.0098	Tray	Insulated	:DE	Stamped / Formed Contacts	Right Angle	Tin	Gold	2	Steel	Copper Alloy	Steel	30.8 x 12.5 x 20.75mm	SMD	9	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+85°C
4 618025226221 25 way male D-sub IDC Connector D-Sub Standard Connectors WR-DSUB Male 25p IDC connector PLUG, D-SUB, IDC, UNC 4-40, 25WAY Wurth Elektronik 618 系列 2.77 mm, 2.84 mm 节距 25 路 IDC D-sub 连接器, 插头, 钢外壳 Wurth Elektronik	73	1: ¥69.1691	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - IDC Dsub	250 V ac	3A	17.25mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.1mm	0.01322	Tray	Insulated	:DB	Stamped / Formed Contacts	Straight	Tin	Gold	2	Steel	Copper Alloy	Steel	53.1 x 12.5 x 17.25mm	SMD	25	:IDC / IDT	Polybutylene Terephthalate (PBT)	Male	618	:50	+85°C
4 61801524823 15 way male D-sub solder Connector D-Sub Standard Connectors WR-DSUB Solder 15P Male Bucket PLUG, D-SUB, SOLDER, 15WAY Wurth Elektronik 618 系列 DB15 15 路电缆安装焊接 D-sub 连接器插头 , 125 V 交流, 3A Wurth Elektronik	78	1: ¥10.4559	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.9mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	39.14mm	0.00597	Tray	Insulated	:DA	Stamped / Formed Contacts	Straight	Nickel	Gold	2	Steel	Copper Alloy	Steel	39.14 x 12.5 x 10.9mm	SMD	15	:Solder	Polybutylene Terephthalate (PBT)	Male	618	:50	+105°C
4 61802524923 25 way female D-sub solder Connector D-Sub Standard Connectors WR-DSUB Solder 25P Female Bucket SOCKET, D-SUB, SOLDER, 25WAY Wurth Elektronik 618 系列电缆安装 DB25 25 路焊接 D-sub 连接器插座 , 125 V 交流, 3A Wurth Elektronik	10	1: ¥18.5276	RoHS Compliant	:No SVHC (20-Jun-2013)	85366990	:WURTH ELEKTRONIK - R/A Solder Mount Dsub	125 V ac	3A	10.7mm	2.77 mm, 2.84 mm	12.5mm	12.5 mm	53.04mm	0.00983	Tray	Insulated	:DB	Stamped / Formed Contacts	Straight	Nickel	Gold	2	Steel	Copper Alloy	Steel	53.04 x 12.5 x 10.7mm	SMD	25	:Solder	Polybutylene Terephthalate (PBT)	Female	618	:50	+105°C
