Broadcom Inc.- 电源管理IC

Broadcom Inc. 是一家全球技术领导者，设计、开发并提供广泛的半导体和基础设施软件解决方案。公司由安华高（Avago Technologies）与Broadcom Corporation于2016年合并成立，沿用Broadcom名称。其美国总部及主要运营基地位于加利福尼亚洲尔湾（Irvine），并在北美、亚洲和欧洲设有办事处和研究机构。产品组合涵盖无线与有线通信、网络、宽带、存储和工业市场。重点产品包括射频前端模块、Wi-Fi/蓝牙组合芯片、GPS/GNSS接收器、以太网交换机和PHY、光纤组件以及定制化ASIC。公司是智能手机、平板电脑、机顶盒、数据中心网络和宽带接入设备的主要供应商。Broadcom拥有行业内最广泛的知识产权组合之一，持有2,600多项美国专利和7,450多项专利申请，覆盖语音、视频、数据和多媒体传输。年收入超过250亿美元，位居全球顶级半导体公司之列，以创新和在消费与企业连接方案中的高市场份额而闻名。其产品践行“Connecting Everything®”的核心理念，连接万事万物。

电源管理IC - 型号列表

共 36 个型号

制造商零件编号	库存	零件状态	包装方式	安装类型	封装形式	供应商器件封装	制造商全称	供电电压	工作温度	输出电流	系列	类型	应用	基础产品编号	调光方式	频率	输出源/灌电流	接口	负载电压	步进分辨率	功能	技术	电机类型 - AC, DC	电机类型 - 步进	输出配置	CMS筛选器头BPN	CMS筛选头系列	DigiKey可编程	标准	最大功率	通道数量	辅助检测	内部开关
LS7262C-S IC MOTOR DRIVER BLDC 28V 20SOIC LSI/CSI	-	Active	Tube	Surface Mount	20-SOIC (0.295", 7.50mm Width)	20-SOIC	LSI/CSI	5V ~ 28V	-40°C ~ 125°C (TA)	4.5mA	-	-	General Purpose	LS7262	-	-	-	-	-	-	Controller - Commutation, Direction Management	NMOS, PMOS	Brushless DC (BLDC)	-	Half Bridge (6)	-	-	-	-	-	-	-	-
LS7362C-S BLDC MOTOR COMMUTATOR/CONTROLLER LSI/CSI	-	Active	Tube	Surface Mount	20-SOIC (0.295", 7.50mm Width)	20-SOIC	LSI/CSI	5V ~ 28V	-40°C ~ 125°C (TA)	-	-	-	General Purpose	-	-	-	-	PWM	-	-	Controller - Commutation, Direction Management	Power MOSFET	Brushless DC (BLDC)	Multiphase	Half Bridge (3)	LS7362	-	-	-	-	-	-	-
LS7541 AGC TOUCH CONTROL STEP DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	-20°C ~ 85°C	-	-	Fluorescent Lamp Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7541	-	-	-	-	-	-	-
LS7635FO TOUCH CONTROL HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	0°C ~ 90°C	300 µA	-	Halogen Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7635	-	-	-	-	-	-	-
LS7636 REVERSE PHASE HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	10V ~ 15V	0°C ~ 90°C	800 µA	-	Halogen Controller	-	LS7636	Yes	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
LS7082N1-S IC CLOCK CONVERTER 14-SOIC LSI/CSI	-	Active	Tube	Surface Mount	14-SOIC (0.154", 3.90mm Width)	14-SOIC	LSI/CSI	-	-	-	-	Clock Converter	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Not Verified	-	-	-	-	-
LS7084N IC CLOCK CONVERTER 8-DIP LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	-	-	-	-	Clock Converter	Interface	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Not Verified	-	-	-	-	-
LS7084N-S IC CLOCK CONVERTER 8-SOIC LSI/CSI	-	Active	Tube	Surface Mount	8-SOIC (0.154", 3.90mm Width)	8-SOIC	LSI/CSI	-	-	-	-	Clock Converter	Interface	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Not Verified	-	-	-	-	-
LS7634 TOUCH CONTROL HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	0°C ~ 90°C	300 µA	-	Halogen Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7634	-	-	-	-	-	-	-
LS7635 TOUCH CONTROL HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	0°C ~ 90°C	300 µA	-	Halogen Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7635	-	-	-	-	-	-	-
BCM59011A0KMLG PSE 30W+ OCTAL POE Broadcom Limited	-	Obsolete	Bulk	-	-	-	Broadcom Limited	-	-	-	-	Controller (PSE)	-	BCM59011	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30 W	1	No	No
LS8297 STEPPER MOTOR CONTROLLER LSI/CSI	-	Active	Tube	Through Hole	20-DIP (0.300", 7.62mm)	20-DIP	LSI/CSI	4.75V ~ 7V	-40°C ~ 150°C (TJ)	-	-	-	General Purpose	LS8297	-	-	-	PWM	-	1, 1/2	Controller - Commutation, Direction Management	Power MOSFET	-	Bipolar, Unipolar	Half Bridge (2)	-	-	-	-	-	-	-	-
LS7262C IC MOTOR DRIVER BLDC 28V 20DIP LSI/CSI	-	Active	Tube	Through Hole	20-DIP (0.300", 7.62mm)	20-DIP	LSI/CSI	5V ~ 28V	-40°C ~ 125°C (TA)	4.5mA	-	-	General Purpose	LS7262	-	-	-	-	-	-	Controller - Commutation, Direction Management	NMOS, PMOS	Brushless DC (BLDC)	-	Half Bridge (6)	-	-	-	-	-	-	-	-
LS7290 STEPPER MOTOR CONTROLLER LSI/CSI	-	Active	Tube	Through Hole	24-DIP (0.600", 15.24mm)	24-DIP	LSI/CSI	3V ~ 5.5V	-20°C ~ 85°C (TA)	-	-	-	General Purpose	LS7290	-	-	-	PWM	-	1, 1/2	Controller - Commutation, Direction Management	Power MOSFET	-	Bipolar, Unipolar	Half Bridge (2)	-	-	-	-	-	-	-	-
LS7540 AGC TOUCH CONTROL LIGHT SWITCH LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	-20°C ~ 85°C	-	-	Ballast Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7540	-	-	-	-	-	-	-
LS7541-S AGC TOUCH CONTROL STEP DIMMER LSI/CSI	-	Active	Tube	Surface Mount	8-SOIC (0.154", 3.90mm Width)	8-SOIC	LSI/CSI	4.5V ~ 5.5V	-20°C ~ 85°C	-	-	Fluorescent Lamp Controller	-	-	Yes	-	-	-	-	-	-	-	-	-	-	LS7541	-	-	-	-	-	-	-
LS7560F-TS BLDC MOTOR CONTROLLER LSI/CSI	-	Active	Tube	Surface Mount	28-TSSOP (0.173", 4.40mm Width)	28-TSSOP	LSI/CSI	5.7V ~ 6.3V	-25°C ~ 85°C (TA)	30mA	-	-	General Purpose	LS7560	-	-	-	PWM	-	-	Controller - Commutation, Direction Management	Power MOSFET	Brushless DC (BLDC)	Multiphase	Half Bridge (3)	-	-	-	-	-	-	-	-
LS7561F-S IC MOTOR DRIVER BLDC 20V 28SOIC LSI/CSI	-	Active	Tube	Surface Mount	28-SOIC (0.295", 7.50mm Width)	28-SOIC	LSI/CSI	20V	-25°C ~ 85°C (TA)	75mA	-	-	General Purpose	LS7561	-	-	-	PWM	-	-	Controller - Commutation, Direction Management	CMOS	Brushless DC (BLDC)	-	Half Bridge (6)	-	-	-	-	-	-	-	-
LS7634FO TOUCH CONTROL HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	4.5V ~ 5.5V	0°C ~ 90°C	300 µA	-	Halogen Controller	-	LS7634	Yes	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
LS7637 REVERSE PHASE HALOGEN DIMMER LSI/CSI	-	Active	Tube	Through Hole	8-DIP (0.300", 7.62mm)	8-DIP	LSI/CSI	10V ~ 15V	0°C ~ 90°C	800 µA	-	Halogen Controller	-	LS7637	Yes	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-

第 1 / 2 页
