图片仅供参考,产品以实物为准
#1 |
数量:2723 |
|
最小起订量:1 新加坡 当天发货，5-8个工作日送达. |
|
|||||||||||||||||
#2 |
数量:84 |
|
最小起订量:1 阿姆斯特丹 当天发货，5-8个工作日送达. |
|
|||||||||||||||||
#3 |
数量:3119 |
|
最小起订量:1 美国费城 当天发货，5-8个工作日送达. |
|
| 规格书 |
 747784 JACKSCREW, MALE, AMPLIMITE , HDP-20 3D PDF MD_747784-3_12122015153_dmtec |
| 文档 |
747784-3 Statement of Compliance RoHS 2 Statement 747784-3.pdf |
| Rohs | Lead free / RoHS Compliant |
| RoHS信息 | 747784-3 Statement of Compliance |
| 三维模型 | 747784-3.pdf |
| 标准包装 | 1 |
| 附件类型 | Jackscrew, Thumb Screw |
| 特点 | - |
| Length - Threaded Portion Below Head | 0.210 (5.30mm) |
| Thread 大小 | 4-40 |
| 类型 | Screw |
| 家庭 | 747784 |
| 标准包装 | Bulk |
| 产品种类 | D-Sub Tools & Hardware |
| RoHS | RoHS Compliant |
| 产品 | Hardware |
| 性别 | Male |
| 螺丝材质 | Stainless Steel |
| 螺丝电镀 | Passivated |
| 工厂包装数量 | 1 |
| 螺纹尺寸 | 4-40 UNC |
| RoHSELV合规性 | RoHS compliant, ELV compliant |
| Lead Free Solder Processes | Not relevant for lead free process |
| GovernmentIndustry资格 | No |
| 品牌 | AMP |
| 包装方式 | Set of Two |
| 包装数量 | 50 |
| 螺杆长度（毫米） | 48.77 [1.920] |
| 产品类型 | Jackscrew |
| RoHSELV符合记录 | Always was RoHS compliant |
| 螺丝表面处理 | None |
| 长度 - 以下的螺纹部分头 | 0.210" (5.30mm) |
| 附件类型 | Jackscrew, Thumb Screw |
| 配用/相关产品 | D-Sub Connectors Series AMPLIMITE |
| RoHS指令 | Lead free / RoHS Compliant |
| 总长 | 48.76mm |
| 产品长度（mm ） | 48.76 mm |
| 产品直径（mm ） | 4.57 mm |
| 适用于 | :D-Subminiature Connector |
| 系列 | :Amplimite |
| Weight (kg) | 0.01 |
| Tariff No. | 85369010 |
| Brand/Series | AMPBrand |
| JackscrewType | Thumbscrew |
| Length,Screw | 1.92in. |
| Material,Body | StainlessSteel |
| Material,Plating | Unplated |
| Material,Screw | StainlessSteel |
| Size,Thread | 4-40UNC |
| 标准 | RoHSCompliant |
| UsedWith | D-SubConnectors |
| associated | 747784-3. |
