点击放大查看

1918680000

制造商	Weidmüller Holding AG & Co. KG
描述	TERMINAL PDK 2.5/V BL Non-Fuse DIN Rail Terminal, 28A, 800V, Blue ,Plug In Termination TERMINAL, PUSH-IN, PDK2.5/4V, BLUE
分类	连接器解决方案接线端子DIN导轨接线端子

对参数有疑问？问 AI 助手

商业参数

标准包装数量

合规参数

RoHS	Compliant	SVHC	:No SVHC (20-Jun-2013)
海关税号	85369010	材料阻燃等级	UL94 V-0

电气参数

电流 - UL	30A	UL电压	600V
电流 - IEC	24A	IEC电压	800V
额定电压	800 V	最大额定电流	28A

机械参数

颜色	Blue	间距	:5.1mm
重量	0.018	导线线规	26 → 10 AWG
端接方式	Plug In	连接器类型	:Terminal Block, DIN Rail
接触镀层	:-	触头材料	:-
剥线长度（范围）	12mm	端子宽度	5.1mm
端接样式	Push In, Spring	连接器颜色	Blue
触点数	:4	位数	4
绝缘材料 - 材质	Thermoplastic	线规或范围 - AWG	10-26 AWG
线规或范围 - mm²	0.5-6mm²	第一连接器安装类型	:DIN Rail

产品信息

类型	Feed Through	系列	PDK
层数	2; Connected

文档与媒体

PDF 文档

Modular Terminal Blocks Catalog

PDF 文档

578410.pdf
