ADS1115IRUGT

制造商	Texas Instruments Incorporated
描述	ADC Single Delta-Sigma 860sps 16-bit Serial 10-Pin X2QFN T/R Analog to Digital Converters - ADC 16B ADC w/ Int MUX PGA Comp Osc & Ref IC ADC 16-BIT I2C PROGBL 10-QFN ADC 16-Bit 0.86KSPS Mux PGA Comp Osc Ref Single ADC Delta-Sigma 860sps 16-bit Serial 10-Pin X2QFN T/R IC, ADC 16BIT 860SPS LP 10QFN 16-Bit ADC with Integrated MUX, PGA, Comparator, Oscillator, and Reference Texas Instruments , 16 位 ADC, 差分输入, I2C接口, 10针 X2QFN封装
分类	集成电路数据转换器模数转换器

对参数有疑问？问 AI 助手

商业参数

其他名称	296-24935-2	产品类别	Analog to Digital Converters - ADC
标准包装数量	Tape & Reel	工厂包装数量	250

合规参数

RoHS	RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
海关税号	85423290	零件状态	ACTIVE
抗辐射加固	No

电气参数

接口	Serial (2-Wire, I2C)	输入类型	Voltage
分辨率	16 Bit	输入信号	Differential, Single Ended
INL/DNL（LSB）	1LSB	输入功率	Single
数据接口	I²C, Serial	输入极性	Bipolar
位数	16	基准类型	Int
数据速率（最大）	860 SPs	额定电压值	�4.096
输出电流	:150µA	输入数量	4
供电电压	2 V to 5.5 V	供电类型	Single
分辨率（位）	:16bit	电压基准	Internal
通道数量	4/2	元件数量	1
采样频率	860 sps	模拟输入/输出	5.5
最大额定电流	Catalog	ADC/DAC 数量	1
供电电源	Single Supply	平均正向功率	0.3
最大功耗	0.5 mW	数字供电电压	5.5
内部供电电压	:2V to 5.5V	采样率（每秒）	8 ~ 860
差分 - 输入:输出	Yes	电源电压范围（典型）	Not Required V
信噪比，ADC/DAC（dB）典型值	Yes

机械参数

宽度	1.55mm	高度	0.35mm
长度	2.05mm	重量	0.0001
包装方式	Reel	端接方式	:SMD
安装类型	Surface Mount	安装样式	SMD/SMT
引脚数	:10	封装形式	10X2QFN
冷却的封装	X2QFN	材料表面处理	:MSL 1 - Unlimited
包装数量	250 \| SMALL T&R	尺寸/外形	2.05 x 1.55 x 0.35mm
位数	10	供应商器件封装	10-X2QFN (2x1.5)

产品信息

系列	ADS1115	软件	SBAS444B
基本单元	:1115	架构	Delta-Sigma
功能框图	fbd_sbas444b.gif	使用的IC/零件	View
A/D转换器数量	4\|2	输入数量及类型	4 Single-Ended, Unipolar; 2 Differential, Bipolar

环境参数

机械寿命	New Technology: Cutting edge technology for the newest designs.	测试温度	-40 to 125
工作温度	+ 140 C
