647016-9

点击放大查看

647016-9

制造商
TE Connectivity Ltd.
描述Conn IDC Connector F 9 POS 2.54mm IDT ST Cable Mount MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RCPT 9POS 22AWG MTA-100 09P MTA100 PSTD CONN ASSY 15AU 09P MTA100 PSTD CONN ASSY 15AU Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP
分类
连接器解决方案矩形连接器电源混合矩形连接器
对参数有疑问？问 AI 助手

商业参数

标准包装规格75标准包装数量Bulk

合规参数

RoHSContains lead / RoHS non-compliantUL等级获得认可
无铅定义Not relevant for lead free processUL档案号E28476
CSA档案号LR7189标准编号CSA, UL
CSA认证CertifiedRoHS/ELV合规状态Not ELV/RoHS compliant
材料阻燃等级UL 94V-2

电气参数

供电电压250额定交流电压250
连接器阻抗IDC最大额定电流5

机械参数

颜色Red间距2.54 mm
高度12.55 mm [ .494 in ]长度25.4 mm [ 1 in ]
包装方式Bulk遮蔽类型No
导线类型Discrete or Ribbon Cable壳体颜色白色
电缆类型分离式导线, 实心, 绞线导线线规22 AWG
端接方式IDT触头类型Male Pin
第二连接器Without外壳颜色Red
安装类型Free Hanging (In-Line)连接器类型Closed End
接触镀层Gold Over Nickel触点时序Without
安装样式不带排数1
壳体镀层Nickel外壳材料（壳体）标准
连接器用途Receptacle插入件材料铜合金
触头材料Copper Alloy壳体材料Nylon
安装特性Without包装数量75
面板安装类型Without电缆端接方式IDC
端接样式插针配接方向Without
触点数9端接表面处理带有
接触件端接Locking Lance绝缘直径1.52 mm [ .06 in ]
位数9兼容外壳尺寸（如TM-700等）MTA .100 标准连接器
触头长度-柱电源安装孔直径带有
接触件表面处理 - 配合锡典型触点布局2.54 [0.100]
接触镀层厚度15µin (0.38µm)恢复后小径No
线规或范围 - mm²0.3-0.4² [22]静电放电屏蔽带有
护套（绝缘）厚度1.27 µm, 50 µin

产品信息

备注肋之间的条纹可能会减少类型IDC Connector
连接器性别F产品特性Closed End
可密封否制造商全称AMP
产品子类型MTA-100 Connectors连接类型Wire
跳过的位置数None

环境参数

工作温度-55 – 105 °C [ -67 – 221 °F ]
