2-87175-4
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing RCP 11 POS 2.54mm Crimp ST Cable Mount Headers & Wire Housings CONN HOUSING 11 POS SINGLE ROW .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 11POS .100 LOCKING Conn Housing RCP 11 POS 2.54mm Crimp ST Cable Mount Product Highlights:ConnectorNot PreloadedHousing Gender = Connector - ReceptacleAccepts Contact Gender = Receptacle2.54 mm CenterlineSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 11 LOCKING CLIP HSG SR .100CL |
| 分类 |
商业参数
| 商标名 | AMPMODU | 其他名称 | A26935 |
| 产品类别 | Headers & Wire Housings | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | RoHS Compliant | 标准编号 | CSA LR7189, UL E28476 |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 额定电压 | 250 VAC | 供电电压 | 250 VAC |
| 接触电阻 | 12 mΩ | 输入电阻 | 5000 |
| 连接器阻抗 | 压接 | 最大额定电流 | 3 A |
| 保护额定电压（VPR） | 750 V | ||
机械参数
| 颜色 | Black | 间距 | 2.54 mm |
| 高度 | 4.44 mm [ .175 in ] | 长度 | 28.34 mm [ 1.12 in ] |
| 锁定类型 | 不带 | 包装方式 | Bulk |
| 壳体颜色 | 黑色 | 导线线规 | 22-30 AWG |
| 排间距 | 2.54 mm | 触头类型 | Female Socket |
| 安装类型 | Straight | 连接器类型 | Receptacle |
| 安装样式 | SMD/SMT | 排数 | 1 |
| 插入件材料 | 磷青铜 | 壳体材料 | Polyester |
| 包装数量 | 1 | 端接样式 | Crimp |
| 第一触头极性 | Socket (Female) | 触点数 | 11 |
| 接触件端接 | Crimp | 位数 | 11 |
| 安装孔直径 | 不带 | 典型触点布局 | 同轴 |
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | RCP | 系列 | AMPMODU Locking Clip |
| 产品子类型 | Receptacles / Sockets - Housings | 其他规格 | 否 |
| 应用细节 | Board-to-Board | ||
环境参数
| 测试温度 | 标准部件 - 非辉光导线 | 工作温度 | - 65 C to + 105 C |
