2-1393546-0
| 制造商 | TE Connectivity Ltd. |
| 描述 | Switch DIP OFF ON SPDT 12 Changeover PC Pins 2.54mm Thru-Hole Tray DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard DIP Switch SPST PCB, 0.5 A, 12-Way, -40 to +85°C Switch DIP OFF ON SPDT 12 Changeover PC Pins 2.54mm Thru-Hole Tray Product Highlights:DIP SwitchPCB Mount Style = Through HoleSingle Pole - Single Throw Configuration (Pole-Throw)Actuator Style = ChangeoverNot SealedSearch Keywords:PCB Switches and Knobs, NIC, Network Interface Cards, PC Cards, Lighting Interconnection Products, Dual In-Line Package, SWITCH DIP SPDT CHNGOVR12POS T/H Switch12waySPSTDIP-FIX Alcoswitch DIP Switch Actuator Style: Changeover Mounting Style: Thru Hole Number of Positions: 12 Configuration: Single Pole - Single Throw Sealed: No |
| 分类 |
对参数有疑问？问 AI 助手
商业参数
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Compliant | 抗辐射加固 | No |
| 无铅定义 | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
电气参数
| 电路 | SPDT | 额定电压 | 60VDC |
| 开关功能 | OFF ON | 最大额定电流 | 500mA |
| 开关功能/额定值 | OFF ON | 触点额定电流 | 0.5 A |
机械参数
| 密封 | No | 深度 | 12.42 mm |
| 间距 | 2.54 mm | 高度 | 8.1 mm |
| 密封型 | No | 包装方式 | Tray |
| 方向 | Top Actuated | 端接方式 | PCBPins |
| 触点形式 | SPSTx12 | 致动器类型 | 3/16" Dia Flatted End |
| 安装类型 | Through Hole | 端子类型 | PC Pins |
| 执行器水平位置 | Raised | 接触镀层 | Tin |
| 安装样式 | Thru Hole | 封装形式 | DIP |
| 插入角度 | No | 触头材料 | Tin Plated Steel |
| 壳体材料 | PBTP | 总长度 | 60.96 mm |
| 端接样式 | PC Pins | 按钮样式/尺寸 | Changeover |
| 位数 | 12 | 开关驱动电平 | SPDT |
| 中心触点材料 | 2.54 [0.100] | 典型触点布局 | SPST |
| 端子柱长度 | 3.10 [0.122] | ||
产品信息
| 备注 | Breakaway for individual connections. | 类型 | DIP |
| 系列 | DIP-FIX | 可清洗 | No |
| 制造商全称 | Alcoswitch | 产品子类型 | DIP Switch |
| 卡标准 | DIP Switch | 配置 | Single Pole - Single Throw |
| 开关数量 | 12 | 转换前位置数 | 12 |
环境参数
| 工作温度 | -40 to 85 °C | ||
