1-794617-4

点击放大查看

1-794617-4

制造商
TE Connectivity Ltd.
描述Conn Housing RCP 14 POS 3mm ST 3mm Centerline, 250V, 5 A max. CONN RCPT 3MM 14POS DL MATE-N-L Housing FH 14 way 2 row Rec M Mate-n-Lok Pin & Socket Connectors RECPT DUAL ROW 14P Conn Housing RCP 14 POS 3mm ST Product Highlights:HousingHousing Type = ReceptacleNumber of Positions = 14Number of Rows = Dual3.00 mm CenterlineSearch Keywords:wire to board, wire to wire, high density, Power Pin & Socket, Soft Shell, Lighting Interconnection, wire to panel, power, pcb connectors, discrete wire, crimp, low profile, Micro MATE-N-LOK connector, MATE-N-LOK connector, Low Profile Soft Shell connector, Lighting, LED Lighting, Lighting Applications, Soft Shell connector, Low profile Micro MATE-N-LOK connector CONN, INLINE PLUG & SOCKET Connector,SoftShell;Nylon;Receptacle;Black;14;Dual;0.118in.;UL94V-0 Crimp housing Pitch3 mm Poles 2 x 14 MATE-N-LOK Micro, 1-794617-4, TE Connectivity TE Connectivity Micro MATE-N-LOK 系列 2 行 3mm 节距 14 路 直 母 连接器外壳 14POS,MICRO MNL,RCPT HSG
分类
连接器解决方案矩形连接器FPC/FFC矩形连接器
对参数有疑问？问 AI 助手

商业参数

产品类别Pin & Socket Connectors标准包装数量Bulk
工厂包装数量1

合规参数

RoHSLead free / RoHS Compliant海关税号85366910
无铅定义Not relevant for lead free processRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL 94V-0

电气参数

额定电压250 V最大额定电流5 A
最小供电电压250VAC

机械参数

颜色Black深度14.04mm
间距3 mm宽度11.7mm
高度11.7 mm长度22mm
重量0.00227包装方式Bulk
导线线规20 AWG排间距0.118" (3.00mm)
触头类型Female Socket外壳颜色Black
安装类型Straight连接器类型Receptacle
紧固类型Latch Lock安装样式Wire
排数2封装形式Receptacle
触头材料Phosphor Bronze壳体材料Nylon
总长度3.00 [0.118]端接样式Crimp
第一触头极性Socket (Female)连接器颜色:Black
触点数14接触件端接Crimp
位数14

产品信息

备注Contacts Not Provided类型Housing
连接器性别RCP系列MATE-N-LOK
产品子类型Housing适用产品/相关产品Centerline Soft Shell Pin & Socket Connector

环境参数

工作温度-40C to 105C

文档与媒体

PDF 文档
1650928.pdf
在线文档
1-794617-4?RQPN=1-794617-4
