点击放大查看

EN3C12F26SX

制造商	Switchcraft, Inc.
描述	Standard Circular Connector 12P FEMALE CORD Conn Weathertight F 12 POS Solder Cup ST Cable Mount 12 Terminal 1 Port Bulk CONN PLUG 12POS FEMALE CORD #26 12PINCORDFEM.STAG Switchcraft 12路电缆安装直向连接器 , 母触点
分类	连接器解决方案圆形连接器标准圆形连接器

对参数有疑问？问 AI 助手

商业参数

商标名	EN3	产品类别	Standard Circular Connector
标准包装数量	1	工厂包装数量	100

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Compliant

电气参数

最大额定电流

机械参数

直径	18.03	包装方式	Bulk
出线方向	No	方向	Keyed
外壳样式	Plug	端接方式	Solder Cup
触头类型	12Signal	安装类型	Cable Mount
外壳镀层	Gold over Nickel	连接器类型	Plug, Female Sockets
接触镀层	Gold Over Nickel	紧固类型	Bayonet Lock
触头材料	Copper Alloy	总长度	55.91
端接排数	焊接	端接样式	Solder Cup
第一触头极性	F	触点数	12
位数	12	外壳材料及表面处理	Thermoplastic Polymer, Glass Fiber

产品信息

类型	Weathertight	系列	EN3
产品特性	Cable Clamp	产品子类型	Connectors

环境参数

防护等级

IP66/68 - Dust Tight, Water Resistant, Waterproof

文档与媒体

PDF 文档

EN3 Series Bulletin

PDF 文档

EN3 Contact size 26 Part Numbering
