点击放大查看
AAA5MZ
| 制造商 | |
| 描述 | XLR Connectors 5 PIN MALE CORD PLUG Conn XLR Connector M 5 POS ST Cable Mount 5 Terminal 1 Port CONN RCPT MALE 5PIN SILVER 5PINMALECORDPLUG Switchcraft 5路 直向 插头 电缆安装 XLR 连接器 , 镀银触点 |
| 分类 |
商业参数
| 产品类别 | XLR Connectors | 标准包装数量 | 1 |
| 工厂包装数量 | 100 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 额定电压 | 125VAC | 供电电压 | Standard XLR |
| 最大额定电流 | 7.5A | ||
机械参数
| 颜色 | 天然色 | 直径 | 19.69 |
| 包装方式 | Bulk | 方向 | Keyed |
| 端接方式 | Solder | 安装类型 | Cable Mount |
| 外壳镀层 | Nickel | 连接器类型 | Receptacle, Male Pins |
| 接触镀层 | Silver | 紧固类型 | Latch Lock |
| 安装样式 | Cable | 触头材料 | Copper Alloy |
| 壳体材料 | 锌合金 | 总长度 | 66.14 |
| 端接排数 | 焊接 | 端接样式 | Solder |
| 触点数 | 5 | 位数 | 5 |
| 外壳尺寸-插件 | XLR | 外壳材料及表面处理 | Zinc Die Cast, Nickel Plated |
产品信息
| 类型 | XLR Connector | 连接器性别 | M |
| 系列 | AAA | 产品特性 | Strain Relief |
| 产品子类型 | Connectors | 端口数 | 1 |
