点击放大查看
TMM-114-01-S-D
| 制造商 | |
| 描述 | Conn Unshrouded Header HDR 28 POS 2mm Solder ST Thru-Hole CONN HEADER 28POS DUAL 2MM T/H |
| 分类 |
商业参数
| 其他名称 | SAM1175-14 | 标准包装数量 | Bulk |
合规参数
| RoHS | Lead free / RoHS Compliant | ||
机械参数
| 颜色 | Black | 间距 | 2 mm |
| 包装方式 | Bulk | 排间距 | 0.079" (2.00mm) |
| 端接方式 | Solder | 触头类型 | Male Pin |
| 安装类型 | Through Hole | 连接器类型 | Header, Unshrouded |
| 接触镀层 | Gold Over Nickel | 排数 | 2 |
| 触点数 | 28 | 位数 | 28 |
| 接触长度 - 配合 | 0.126" (3.20mm) | 接触镀层厚度 | 30µin (0.76µm) |
产品信息
| 类型 | Unshrouded Header | 连接器性别 | HDR |
| 加载位置数 | All | ||
文档与媒体
