3201851

制造商	Phoenix Contact GmbH & Co. KG
描述	CONN TERM BLK 12-28AWG Installation level terminal block STI 2,5-L/N DIN Rail Terminal Blocks STI 2.5-L/N Installation level terminal block, Spring-cage connection, Cross section: 0.08 mm² - 4 mm², AWG: 28 - 12, Width: 5.2 mm, Color: gray, Mounting type: NS 35/7,5, NS 35/15 STI25-L/N
分类	连接器解决方案接线端子DIN导轨接线端子

对参数有疑问？问 AI 助手

商业参数

商标名	CLIPLINE ST	其他名称	STI 2 5-L/N
标准包装数量	50	工厂包装数量	50

合规参数

RoHS

Not Applicable

材料阻燃等级

UL94 V-0

电气参数

电流 - UL	20A	UL电压	300V
电流 - IEC	24A	IEC电压	400V

机械参数

颜色	Gray	剥线长度（范围）	10mm
端子宽度	5.2mm	端接样式	Push In, Spring
位数	4	绝缘材料 - 材质	Polyamide (PA), Nylon
线规或范围 - AWG	12-28 AWG	线规或范围 - mm²	0.08-4mm²

产品信息

类型	Feed Through	系列	ST
层数	2
