3037533

制造商	Phoenix Contact GmbH & Co. KG
描述	CONN TERM BLOCK Feed-through modular terminal block STS 4-TWIN OG DIN Rail Terminal Blocks STS 4-TWIN OG STS4-TWINOG
分类	连接器解决方案接线端子DIN导轨接线端子

对参数有疑问？问 AI 助手

商业参数

商标名	CLIPLINE ST	其他名称	STS 4-TWIN OG
标准包装数量	50

合规参数

RoHS

Not Applicable

材料阻燃等级

UL94 V-0

电气参数

电流 - UL	30A	UL电压	600V
电流 - IEC	32A	IEC电压	800V

机械参数

颜色	Orange	剥线长度（范围）	10mm
端子宽度	6.2mm	端接样式	Push In, Spring
位数	3	线规或范围 - AWG	10-28 AWG
线规或范围 - mm²	0.08-6mm²

产品信息

类型	Feed Through	系列	ST
层数	1
