点击放大查看
3008009
| 制造商 | Phoenix Contact GmbH & Co. KG |
| 描述 | DIN Rail Terminal Blocks UK 35-IB Misc Products CONN TERM BLOCK Feed-through modular terminal block UK 35-IB UK35-IB Phoenix Contact UK 系列 灰色 DIN 导轨端子 , 150A, 1000 V |
| 分类 |
商业参数
| 商标名 | CLIPLINE UK | 其他名称 | UK 35-IB |
| 标准包装规格 | 1 | 产品类别 | DIN Rail Terminal Blocks |
| 标准包装数量 | 1 | 工厂包装数量 | 1 |
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 材料阻燃等级 | UL94 V-0 | ||
电气参数
| 电流 - IEC | 150A | IEC电压 | 1000V |
| 额定电压 | 1000 V | 最大额定电流 | 150A |
机械参数
| 颜色 | Gray | 重量 | 2 oz |
| 剥线长度（范围） | 16mm | 端子宽度 | 15.1mm |
| 端接排数 | 螺钉 | 端接样式 | Screw |
| 位数 | 2 | 绝缘材料 - 材质 | Polyamide (PA), Nylon |
| 线规或范围 - AWG | 1/0-18 AWG | 线规或范围 - mm² | 0.75-50mm² |
产品信息
| 类型 | Feed Through | 系列 | UK |
| 叠层数 | 单层 | 层数 | 1 |
文档与媒体
