2961134
| 制造商 | Phoenix Contact GmbH & Co. KG |
| 描述 | General Purpose Relays REL-MR- 60DC/21AU REPLACEMENT RELAY Electromechanical Relay SPDT 0.05A 60VDC 20.5KOhm Plug-In RELAY GEN PURPOSE SPDT 50MA 60V REL-MR- 60DC/21AU Relay;E-Mech;Power;SPDT;Cur-Rtg50mA;Ctrl-V60VDC;Vol-Rtg30VAC/36VDC;PCBMnt; |
| 分类 |
商业参数
| 交货时间 | 28 Days | 商标名 | INTERFACE Relay |
| 子类别 | Electromechanical Relay | 产品类别 | General Purpose Relays |
| 标准包装数量 | 10 | 工厂包装数量 | 10 |
合规参数
| RoHS | RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 线圈类型 | Non Latching | 线圈电流 | 3 mA |
| 释放时间 | 2.5ms | 可见输出 | No |
| 额定电压 | 36 | 线圈电阻 | 20500 Ohms |
| 推频（MHz/V） | No | 供电电压 | 60 V |
| 开关电压 | 30VAC, 36VDC - Max | 二极管配置 | No |
| 最大额定电流 | 0.05 | 最小输入电压 | 30 |
| 平均正向功率 | 1.2 W | 触点额定电流 | 50mA |
机械参数
| 密封 | Unsealed | 深度 | 5 |
| 高度 | 15 | 重量 | 0.233514 oz |
| 包装方式 | Bulk | 触点形式 | 1 Form C (SPDT-BM) |
| 安装类型 | Plug-In | 安装样式 | Plug In |
| 冷却的封装 | SIP | 触头材料 | Silver Tin Oxide |
| 总长度 | 28 | 端接样式 | Solder Pin |
| 触点数 | 5 | 接触件端接 | PCB |
| 典型触点布局 | SPDT | ||
产品信息
| 类型 | Interface | 系列 | REL-MR |
| 继电器类型 | Non-Latching | 行业别名 | REL-MR- 60DC/21AU |
| 基础产品编号 | REL-MR-60DC/21AU | ||
环境参数
| 动作时间 | 5ms | 工作温度 | -40°C ~ 85°C |
