点击放大查看
0709026
| 制造商 | Phoenix Contact GmbH & Co. KG |
| 描述 | Fixed Terminal Blocks HDFKV 4 Conn Feed-Thru F 2 POS Screw Wall Mount 41A TERM BLK FEED-THRU 1-4MM WALL GY Conn;TermBlk;Panel;FeedThru;Screw;2;24-10AWG;8.1mm;Gray;32A; |
| 分类 |
商业参数
| 产品 | Fixed Terminal Blocks | 交货时间 | 20 Days |
| 商标名 | COMBICON Power | 子类别 | Connector Terminal Blocks |
| 产品类别 | Fixed Terminal Blocks | 标准包装数量 | 50 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 认证机构 | cULus,CSA | ||
电气参数
| 电流 - UL | 30A | UL电压 | 300V |
| 额定电压 | 400 V | 极数 | 2Poles |
| 最大额定电流 | 32 A | 最小输入电压 | 400V |
机械参数
| 颜色 | Gray | 深度 | 64.5 |
| 宽度 | 0.319" (8.10mm) | 高度 | 23.5 |
| 重量 | 0.312598 oz | 导线线规 | 10-30 AWG |
| 端接方式 | Screw | 安装类型 | Wall Mount |
| 安装样式 | Free Hanging | 排数 | 2 |
| 面板厚度 | 0.039 ~ 0.158" (1.0 ~ 4.0mm) | 壳体材料 | Polyamide |
| 面板安装类型 | 2 Piece | 主要材料 | Panel |
| 插针孔直径 | 8.1mm | 端接样式 | Screw |
| 触点数 | 2 | 线规或范围 - mm² | 10 |
| 后面板接线方式 | Bolt/Screw Clamp - Wire Entry Parallel to Panel | 前面板接线方式 | Bolt/Screw Clamp - Wire Entry 90° to Panel |
产品信息
| 类型 | Feed-Thru | 连接器性别 | F |
| 行业别名 | HDFKV 4 | 层数 | 1 |
| 每层位数 | 1 | ||
