POE125U-4-AT-N

制造商	Phihong Technology Co., Ltd.
描述	POWER SUPPLY 4PORT POE INJECTOR 33.6W DESKTOP

对参数有疑问？问 AI 助手

商业参数

标准包装数量

合规参数

合规性

IEEE802.3at

认证机构

CE, cULus

电气参数

数据速率	10/100/1000 Mbps	效率	75%
最小输入电压	90 ~ 264 VAC	每端口功率（瓦）	33.6W

机械参数

重量	3 lbs (1.4kg)	安装类型	Desktop
输入连接器	IEC320-C14 (Power), RJ45 (Data)	输出连接器	RJ45 (Data, Power)
尺寸/外形	8.85" L x 7.87" W x 1.91" H (224.9mm x 200.0mm x 48.5mm)

产品信息

备注	AC Power Cord Sold Separately	类型	Midspan Injector
产品特性	OCP, OTP, OVP, SCP	端口数	4

环境参数

工作温度

0°C ~ 40°C

文档与媒体

PDF 文档

POE125U-4AT-(x)
